H8PS
Dimensions
Note: All units are in millimeters unless otherwise indicated.
■ Main Unit
Cam Positioners
Panel Cutout
15.2
Flush Mounting Models
H8PS-8B@ (8-output Models)
21.6
M3.5 terminal screw
(according to DIN 43700)
92+0.8
0
(14.6)
52.9
46
92+0.8
0
12
96
Note: Mounting panel thickness must be 1 to
91.8 × 91.8
96
5 mm.
Flush mounting
14.6
52.9
α
(14.6)
52.9
46
H8PS-16B@ (16-output Models)
H8PS-32B@ (32-output Models)
12
96
11 dia.
96
91.8 × 91.8
Mounting screws
(2 included) (M4 x 12)
Mounting bracket (included)
Mounting panel
(1 to 5 mm)
52.3 + α
Note: An 8-output Model is shown in the above
diagrams. The Encoder is connected
from the bottom with 16-/32-output
Models.
M3.5 terminal screw
21.6
15.2
Mounting holes
Terminal cover
Surface Mounting Models
H8PS-8BF@ (8-output Models)
M3.5 terminal screw
0.2
81.8
(60.6)
58
46
22.9
96
0.3
115.2
91.8 × 91.8
96
121.2
Four, M4 tap holes
Surface
Track
16
16
90
96
Mounting
Mounting
(60.6)
58
46
H8PS-16BF@ (16-output Models)
H8PS-32BF@ (32-output Models)
74.4
60.6
(See note 1.)
96
91.8 × 91.8
DIN Track
121.2
DIN Track Mounting Base
Y92F-91
(Order Separately)
16
16
22.9
90
Note: 1. These dimensions vary with the kind
of DIN track (reference value).
2. An 8-output Model is shown in the
above diagrams. The Encoder is
connected from the bottom with 16-/
32-output Models.
M3.5 terminal screw
Terminal cover
12
