CJ2M-CPU3@/-CPU1@/-MD21@
Specifications of Pulse I/O Modules
Input Specifications (IN00 to IN09/IN10 to IN19 )
Normal Inputs
IN00 to IN05 and
IN10 to IN15
IN06 to IN09 and
IN16 to IN19
IN00 to IN05 and
IN10 to IN15
IN06 to IN09 and
IN16 to IN19
Inputs
Input form
24 VDC inputs
6.0 mA typical
Line driver inputs
13 mA typical
Input current
5.5 mA typical
10 mA typical
RS-422A or RS-422 line driver (conforming to AM26LS31),
Power supply voltage of 5 V 5%
Input voltage range
24 VDC +10%/−15%
Input impedance
3.6 kΩ
4.0 kΩ
---
Number of circuits
ON voltage/current
OFF voltage/current
ON response time
OFF response time
1 common, 1 circuit
17.4 VDC min., 3 mA min.
1 mA max. at 5 VDC max.
---
---
8 ms max. (The input time constant can be set to 0, 0.5, 1, 2, 4, 8, 16, or 32 ms in the PLC Setup.)
8 ms max. (The input time constant can be set to 0, 0.5, 1, 2, 4, 8, 16, or 32 ms in the PLC Setup.)
Input Circuit Configuration
Item
Specifications
Input
IN00 to IN05/IN10 to IN15
IN06 to IN09/IN16 to IN19
24 V
24 V
LD+
LD+
Circuit configuration
Interrupt Input and Quick-response Input Specifications (IN00 to IN03 and IN10 to IN13)
Item
Specifications
ON response time
OFF response time
30 μs max.
150 μs max.
30 μs min.
150 μs min.
ON
Response pulse
OFF
17
