CJ2M-CPU3@/-CPU1@/-MD21@
Output Specifications (OUT00 to OUT05 and OUT10 to OUT15)
Item
Specifications
Output Specifications
Rated voltage
Sinking-type (CJ2M-MD211)
5 to 24 VDC
Sourcing-type (CJ2M-MD212)
Allowable voltage range
4.75 to 26.4 VDC
Maximum switching
current
0.3 A/output, 1.8 A/Unit
Number of circuits
6 outputs (6 outputs/common)
Maximum inrush current 3.0 A/output, 10 ms max.
2.0 A/output, 10 ms max.
Leakage current
Residual voltage
ON response time
OFF response time
Fuse
0.1 mA max.
0.6 V max.
0.1 ms max.
0.1 ms max.
None
External supply power
(power supply input for
outputs)
10.2 to 26.4 VDC, 20 mA min.
Rated
voltage
circuit
+V
COM
OUT
Circuit configuration
OUT
Isolation
circuit
Isolation
circuit
Rated
voltage
circuit
COM
Pulse Outputs (OUT00 to OUT03 and OUT10 to OUT13)
Item
Specifications
Output Specifications
Rated voltage
Sinking-type (CJ2M-MD211)
5 to 24 VDC
Sourcing-type (CJ2M-MD212)
Allowable voltage range
4.75 to 26.4 VDC
Maximum switching
capacity
30 mA
7 mA
Minimum switching
capacity
Maximum output
frequency
100 kHz
ON
OFF
90%
90%
Output waveform
10%
10%
ON
OFF
4 μs min.
2 μs min.
2 μs min.
4 μs min.
PWM Outputs (OUT04, OUT05, OUT14, and OUT15)
Item
Specifications
Sourcing-type (CJ2M-MD212)
Output Specifications
Rated voltage
Sinking-type (CJ2M-MD211)
5 to 24 VDC
Allowable voltage range
4.75 to 26.4 VDC
Maximum switching
capacity
6.5535 kHz or less: 300 mA, 6.5535 to 32.8 kHz: 100 mA
32,800 Hz
Maximum output
frequency
PWM output accuracy
(for ON pulse width of
2 μs or longer)
ON duty at 6.5535 kHz or less: -0.2% to +1%,
ON duty at 32.8 kHz: -1% to +5%
(at switching current of 30 mA)
ON duty at 6.5535 kHz or less: 0.5%,
ON duty at 32.8 kHz: +2.5%
(at switching current of 30 mA)
ON
OFF
50%
ON
50%
Output waveform
OFF
tON
tON
tON
tON
T
X 100%
ON duty =
X 100%
ON duty =
T
T
T
19
