CP1E-E@@D@-@ CP1E-N@@D@-@/NA20D@-@
Options (for CP1E N30/40/60 or NA20 CPU Units)
The Options cannot be used for CP1E N14/20 CPU Units and all E-type CPU Units.
Product name
Specifications
Model
Standards
RS-232C Option Board
One RS-232C Option Board can be mounted to the Option Board slot.
For CP1E N30/40/60 or NA20 CPU Units only.
One RS-232C connector is included.
CP1W-CIF01
UC1, N,
L, CE
RS-422A/485 Option Board
CP1W-CIF11
CP1W-CIF12
CP1W-CIF41
One RS-422A/485 Option Board can be mounted to the Option Board slot.
For CP1E N30/40/60 or NA20 CPU Units only.
RS-422A/485 Isolated-type
Option Board
UC1, N,
L, CE
Ethernet Option Board
One Ethernet Option Board can be mounted to the Option Board slot.
CP1E CPU Units are supported by CP1W-CIF41 version 2.0 or higher.
For CP1E N30/40/60 or NA20 CPU Units only.
UC1, N,
L, CE
When using CP1W-CIF41, CX-Programmer version 9.12 or higher is required.
Note: It is not possible to use a CP-series Ethernet Option Board version 1.0 (CP1W-CIF41), LCD Option Board (CP1W-DAM01), or Memory Card
(CP1W-ME05M) with a CP1E CPU Unit.
Programming Devices
Specifications
Product name
Model
Standards
Number of
licenses
Media
CX-One Lite is a subset of the complete CX-One package that
provides only the Support Software required for micro PLC
applications.
FA Integrated Tool Package
CX-One Lite
Ver.4.@
CX-One Lite runs on the following OS.
1 license
CD
CXONE-LT01C-V4
--
OS: Windows XP (Service Pack 3 or higher), Vista or 7
Note: Except for Windows XP 64-bit version.
CX-One Lite Ver. 4.@ includes Micro PLC Edition CX-
Programmer Ver.9.@.
CX-One is a comprehensive software package that integrates
Support Software for OMRON PLCs and components. CX-
One runs on the following OS.
OS: Windows XP (Service Pack 3 or higher), Vista or 7
Note: Except for Windows XP 64-bit version.
FA Integrated Tool Package
CX-One
Package Ver. 4.@
1 license *1 DVD *2
CXONE-AL01D-V4
--
CX-One Ver. 4.@ includes CX-Programmer Ver. 9.@.
Note: 1. The E20, E30, E40, N20, N30 and N40 CPU Units are supported by CX-Programmer version 8.2 or higher.
The E10, E14, N14, N60, and NA20 CPU Units are supported by CX-Programmer version 9.03 or higher.
When Micro PLC Edition CX-Programmer is used, you need version 9.03 or higher.
2. The CX-One and CX-One Lite cannot be simultaneously installed on the same computer.
* 1 Multi licenses are available for the CX-One (3, 10, 30 or 50 licenses).
* 2 The CX-One is also available on CD (CXONE-AL@@C-V4).
The following tables lists the Support Software that can be installed from CX-One
CX-One Lite
Ver.4.@
CX-One
Ver.4.@
CX-One Lite
Ver.4.@
CX-One
Ver.4.@
Support Software in CX-One
Support Software in CX-One
Micro PLC Edition CX-Programmer
CX-Programmer
CX-Integrator
Ver.9.@
Ver.9.@
Ver.2.@
Ver.1.@
Ver.1.@
Ver.1.@
Ver.2.@
Ver.1.@
Ver.2.@
Ver.2.@
Yes
No
No
CX-Drive
Ver.2.@
Ver.5.@
Ver.3.@
Ver.3.@
Ver.1.@
Ver.4.@
Ver.1.@
Ver.1.@
Ver.3.@
Ver.4.@
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CX-Process Tool
Faceplate Auto-Builder for NS
CX-Designer
Yes
Yes
No
No
Switch Box Utility
CX-Protocol
Yes
Yes
Yes
Yes
No
NV-Designer
CX-Simulator
Yes
No
CX-Thermo
CX-Position
CX-ConfiguratorFDT
CX-FLnet
CX-Motion-NCF
CX-Motion-MCH
CX-Motion
No
No
Network Configurator
CX-Server
Yes
Yes
No
Note: For details, refer to the CX-One Catalog (Cat. No. R134).
