CP1E-E@@D@-@ CP1E-N@@D@-@/NA20D@-@
CP1E-N@@D@-@
CP1E-NA@@D@-@
Item
CP1E-E@@D@-@
Conforming to USB 2.0 B type connector
5 m max.
B-type Peripheral USB Port
Transmission
distance
Built-in RS-232C port
Interface: Conforms to EIA RS-232C.
Half duplex
Communications
method
synchronization
Baud rate
Start-stop
1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, or 115.2 kbps
Transmission
distance
No built-in RS-232C port
15 m max.
• Host Link
• 1:N NT Link
Supported
protocol
• No-protocol mode
• Serial PLC Links (master, slave)
• Modbus-RTU Easy Master
Communications
1 port (Option Board can be mounted only to N30/40/
60 and NA20 CPU Units.)
Serial Option port
• One RS-232C port: CP1W-CIF01
Mountable
Option Boards
• One RS-422A/485 port (not isolated): CP1W-CIF11
• One RS-422A/485 port (isolated): CP1W-CIF12
• One Ethernet port: CP1W-CIF41
Communications
method
Depends on Option Board.
Option Board cannot be mounted.
synchronization
Baud rate
Depends on Option Board.
1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, or 115.2 kbps
• Host Link
• 1:N NT Link
Compatible
protocols
• No-protocol mode
• Serial PLC Links (master, slave)
• Modbus-RTU Easy Master
17
• One cyclic execution task
Number of tasks
• One scheduled interrupt task (always interrupt task 1)
• Six input interrupt tasks (interrupt tasks 2 to 7)
• Sixteen high-speed counter interrupt tasks (interrupt tasks 1 to 16)
Maximum subroutine number
Maximum jump number
128
128
Scheduled interrupt tasks
1 interrupt task
Included.
Accuracy (monthly deviation):
Clock function not included.
Clock
The time of error occurrence displays 01-01-01
01:01:01 Sunday
-4.5 min to -0.5 min at ambient temperature of 55oC,
-2.0 min to +2.0 min at ambient temperature of 25oC,
-2.5 min to +1.5 min at ambient temperature of 0oC
Ladder programs and parameters are automatically saved to built-in EEPROM
A section of the Data Memory Area can be saved to the built-in EEPROM.
Built-in EEPROM
CP1W-BAT01 can be used.
Maximum battery service life: 5 years
Backup Time
Memory
backup
Battery backup With
CP1W-BAT01 Battery
(Sold separately)
Battery cannot be mounted.
Guaranteed value (ambient temperature: 55oC):
13,000 hours (approx. 1.5 years)
Effective value (ambient temperature: 25oC):
43,000 hours (approx. 5 years)
Input Bits
1,600 bits (100 words): CIO 0.00 to CIO 99.15 (CIO 00 to CIO 99)
1,600 bits (100 words): CIO 100.00 to CIO 199.15 (CIO 100 to CIO 199)
1,440 bits (90 words): CIO 200.00 to CIO 289.15 (words CIO 200 to CIO 289)
1,600 bits (100 words): W0.00 to W99.15 (W0 to W99)
CIO Area
Output Bits
Serial PLC Link Words
Work Area (W)
800 bits (50 words): H0.00 to H49.15 (H0 to H49)
Bits in this area maintain their ON/OFF status when operating mode is changed.
Holding Area (H)
Read-only: 7,168 bits (448 words) A0 to A447
Read/write: 4,896 bits (306 words) in words A448 to A753
Auxiliary Area (A)
Temporary Relay Area (TR) (TR Area)
Timer Area (T)
16 bits: TR0 to TR15
256 timer numbers (T0 to T255 (separate from counters))
256 counter numbers (C0 to C255 (separate from timers))
Counter Area (C)
2 Kwords: D0 to D2047
8 Kwords: D0 to D8191
Of these, 1,500 words can be saved to the backup
memory (built-in EEPROM) using settings in the
Auxiliary Area.
Of these, 7,000 words can be saved to the backup
memory (built-in EEP-ROM) using settings in the
Auxiliary Area
Data Memory Area (D)
Operating modes
PROGRAM mode: Program execution is stopped.
Preparations can be executed prior to program execution in this mode.
MONITOR mode: Programs are executed.
Some operations, such as online editing, and changes to present values in I/O memory, are
enabled in this mode.
RUN mode: Programs are executed.
This is the normal operating mode.
10
