CP1E-E@@D@-@ CP1E-N@@D@-@/NA20D@-@
Current
consumption (A)
External
power
supply
(24 VDC)
(A)
Specifications
Output
Product
name
Model
Standards
Data
memory
capacity
Power
Program
capacity
Inputs Outputs
5 V
24 V
Supply
type
NA-type
CPU Units
with 20 I/O
Points
(Built-in
analog)
100 to 240
VAC
Relay
0.30
--
0.18
0.11
CP1E-NA20DR-A
CP1E-NA20DT-D
CP1E-NA20DT1-D
12
8
Transistor 8K
(sinking) steps
8K
words
UC1, N,
L, CE
(Built-in
analog
inputs: 2) outputs: 1)
(Built-in
analog
0.23
0.23
0.09
0.09
24 VDC
Transistor
(sourcing)
--
Battery Set For N/NA-type CP1E CPU Units
Note: Mount a Battery to an N/NA-type CPU Unit if the data in the following areas must be
backed up for power interruptions.
• DM Area (D) (except backed up words in the DM Area), Holding Area (H), Counter Completion Flags (C),
Counter Present Values (C), Auxiliary Area (A), and Clock Function
(Use batteries within two years of manufacture.)
CP1W-BAT01
--
Note: There are no accessories included with N/NA-type CP1E CPU Units. RS-232C connectors for the built-in RS-232C port and the Battery
(CP1W-BAT01) are not included.
5
