Nano100(A)
and TMR1_CH1) to enable ADC
SmartCard (SC)
Compliant to ISO-7816-3 T=0, T=1
Supports up to two ISO-7816-3 ports
Separates receive/transmit 4 bytes entry FIFO for data payloads
Programmable transmission clock frequency
Programmable receiver buffer trigger level
Programmable guard time selection (11 ETU ~ 267 ETU)
A 24-bit and two 8 bit time out counters for Answer to Request (ATR) and
waiting times processing
Supports auto inverse convention function
Supports transmitter and receiver error retry and error limit function
Supports hardware activation sequence process
Supports hardware warm reset sequence process
Supports hardware deactivation sequence process
Supports hardware auto deactivation sequence when detect the card is removal
EBI (External bus interface) support
Accessible space: 64 KB in 8-bit mode or 128 KB in 16-bit mode
Supports 8bit/16bit data width
Supports byte write in 16-bit Data Width mode
One built-in temperature sensor with 1℃ resolution
96-bit unique ID
Operating Temperature: -40℃~85℃
Packages:
All Green package (RoHS)
LQFP 100-pin(14x14) / 64-pin(7x7) / 48-pin(7x7) / QFN 33-pin(5x5)
