Nano100(A)
2
FEATURES
The equipped features are dependent on the product line and their sub products.
2.1 Nano100 Features – Base Line
Core
ARM® Cortex™-M0 core running up to 32 MHz
One 24-bit system timer
Supports Low Power Sleep mode
Single-cycle 32-bit hardware multiplier
NVIC for the 32 interrupt inputs, each with 4-levels of priority
Serial Wire Debug supports with 2 watchpoints/4 breakpoints
Brown-out
Built-in 2.5V/2.0V/1.7V BOD for wide operating voltage range operation
Flash EPROM Memory
Runs up to 32 MHz with zero wait state for discontinuous address read access
64K/32K bytes application program memory (APROM)
4 KB in system programming (ISP) loader program memory (LDROM)
Programmable data flash start address and memory size with 512 bytes page
erase unit
In System Program (ISP)/In Application Program (IAP) to update on-chip Flash
EPROM
SRAM Memory
16K/8K bytes embedded SRAM
Supports DMA mode
DMA: Supports 5 channels: one VDMA channel and 4 PDMA channels
VDMA
Memory-to-memory transfer
Supports block transfer with stride
Supports word/half-word/byte boundary address
Supports address direction: increment and decrement
PDMA
Peripheral-to-memory, memory-to-peripheral, and memory-to-memory
transfer
Supports word boundary address
Supports word alignment transfer length in memory-to-memory mode
Supports word/half-word/byte alignment transfer length in peripheral-to-
memory and memory-to-peripheral mode
Supports word/half-word/byte transfer data width from/to peripheral
Supports address direction: increment, fixed, and wrap around
