Device operations
NAND01G-B2B, NAND02G-B2C
6.9
Read electronic signature
The device contains a manufacturer code and device code. To read these codes three steps
are required:
1. One bus write cycle to issue the Read Electronic Signature command (90h)
2. One bus write cycle to input the address (00h)
3. Four bus read cycles to sequentially output the data (as shown in Table 14: Electronic
signature).
Table 14. Electronic signature
byte/word 1
byte/word 2
Device code
byte/word 3
byte/word 4
Part number
Manufacturer
code
(see Table 15)
(see Table 16)
NAND01GR3B2B
NAND01GW3B2B
NAND01GR4B2B
NAND01GW4B2B
NAND02GR3B2C
NAND02GW3B2C
NAND02GR4B2C
NAND02GW42C
A1h
F1h
B1h
C1h
AAh
DAh
BAh
CAh
15h
1Dh
55h
5Dh
15h
1Dh
55h
5Dh
20h
0020h
20h
80h
0020h
Table 15. Electronic signature byte 3
I/O
Definition
Value
Description
0 0
0 1
1 0
1 1
1
2
4
8
I/O1-I/O0
Internal chip number
0 0
0 1
1 0
1 1
2-level cell
4-level cell
8-level cell
16-level cell
I/O3-I/O2
I/O5-I/O4
Cell type
0 0
0 1
1 0
1 1
1
2
4
8
Number of simultaneously
programmed pages
0
1
Not supported
supported
Interleaved programming
between multiple devices
I/O6
I/O7
0
1
Not supported
supported
Cache program
32/60
