µPD703100A-33, 703100A-40, 703101A-33, 703102A-33
(9) Interrupt timing
Parameter
NMI high-level width
NMI low-level width
Symbol
<132>
Condition
MIN.
500
MAX.
Unit
ns
tWNIH
tWNIL
tWITH
tWITL
<133>
<134>
<135>
500
ns
INTPn high-level width
INTPn low-level width
4T + 10
4T + 10
ns
ns
Remarks 1. n = 100 to 103, 110 to 113, 120 to 123, 130 to 133, 140 to 143, or 150 to 153
2. T = tCYK
<132>
<134>
<133>
NMI (Input)
<135>
INTPn (Input)
Remark n = 100 to 103, 110 to 113, 120 to 123, 130 to 133, 140 to 143, or 150 to 153
(10) RPU timing
Parameter
TI1n high-level width
Symbol
<136>
Condition
MIN.
MAX.
Unit
ns
tWTIH
tWTIL
tWTCH
tWTCL
3T + 18
3T + 18
3T + 18
3T + 18
TI1n low-level width
<137>
<138>
<139>
ns
TCLR1n high-level width
TCLR1n low-level width
ns
ns
Remarks 1. n = 0 to 5
2. T = tCYK
<136>
<137>
TI1n (Input)
<138>
<139>
TCLR1n (Input)
Remark n = 0 to 5
