µPD703100A-33, 703100A-40, 703101A-33, 703102A-33
A/D Converter Characteristics (TA = –40 to +70°C ... µPD703100A-40,
TA = –40 to +85°C ... µPD703100A-33, µPD703101A-33, µPD703102A-33,
VDD = HVDD = CVDD = 3.0 to 3.6 V, VSS = 0 V,
VDD – 0.5 V ≤ AVDD ≤ VDD, output pin load capacitance: CL = 50 pF)
Parameter
Symbol
–
Condition
MIN.
10
TYP.
MAX.
Unit
bit
Resolution
Total error
–
±5
± 1/2
10
LSB
LSB
µs
Quantization error
Conversion time
Sampling time
–
tCONV
tSAMP
–
5
833
ns
Zero scale error
Full scale error
±5
±5
LSB
LSB
LSB
V
–
Nonlinearity error
Analog input voltage
Analog input resistance
AVREF input voltage
AVREF input current
AVDD current
–
±3
VIAN
RAN
AVREF
AIREF
AIDD
−0.3
AVREF + 0.3
1.0
MΩ
V
AVREF = AVDD
3.0
AVDD
2.0
mA
mA
5.0
125
Preliminary Data Sheet U14168EJ2V0DS00
