µPD703100A-33, 703100A-40, 703101A-33, 703102A-33
(7) DMAC timing
Parameter
Symbol
Condition
Unit
ns
MIN.
MAX.
DMARQn setup time (to CLKOUT ↑)
DMARQn hold time (from CLKOUT ↑)
<116>
tSDRK
tHKDR1
tHKDR2
tDKDA
10
<117>
<118>
<119>
2
ns
Until DMAAKn ↓
ns
DMAAKn output delay time
2
10
10
10
10
ns
(from CLKOUT ↓)
DMAAKn output hold time
<120>
<121>
<122>
tHKDA
tDKTC
tHKTC
2
2
2
ns
ns
ns
(from CLKOUT ↓)
TCn output delay time
(from CLKOUT ↓)
TCn output hold time
(from CLKOUT ↓)
Remark n = 0 to 3
CLKOUT (Output)
<117>
<116>
<118>
DMARQn (Input)
DMAAKn (Output)
<116>
<119>
<120>
<122>
<121>
TCn (Output)
Remark n = 0 to 3
