Notice
■ Others
1. Transportation
1-2. Do not apply excessive vibration, shock, and
pressure to the capacitor.
1. The performance of a capacitor may be affected by the
conditions during transportation.
1-1. The capacitors shall be protected against
excessive temperature, humidity and mechanical
force during transportation.
(1) When excessive mechanical shock or pressure
is applied to a capacitor, chipping or cracking
may occur in the ceramic body of the capacitor.
(2) When a sharp edge of an air driver, a soldering
iron, tweezers, a chassis, etc. impacts strongly
on the surface of capacitor, the capacitor may
crack and short-circuit.
(1) Climatic condition
• low air temperature: -40°C
• change of temperature air/air: -25°C/+25°C
• low air pressure: 30 kPa
1-3. Do not use a capacitor to which excessive shock
was applied by dropping, etc.
• change of air pressure: 6 kPa/min.
(2) Mechanical condition
The capacitor dropped accidentally during
processing may be damaged.
Transportation shall be done in such a way that
the boxes are not deformed and forces are not
directly passed on to the inner packaging.
