Package Outlines
D
e
ZD
R
A
E
H
A1
Pin #1
B
70
±0.20
0.51 x 45°
±0.10
0.63
±.008
(.020)
7°
±.004
(.025)
GAGE
PLANE
C
L
DETAIL - A
Q
Notes:
A
1. Lead Coplanarity should be 0 to 0.10mm (.004") max
2. Package surface finishing
(2.1) Top Matte: (Charmilles #18-30)
(2.2) All Sides: (Charmilles #18-30)
(2.3) Bottom Matte: (Charmilles #18-30)
3. All dimensions excluding mold flashes
4. Max. deviation of center of package and center of leadrame to be 0.10mm (.004")
5. Max. misalignment between top and bottom center of package to 0.10mm (.004")
6. End flash from the package body shall not exceed 0.152 (.006") per side (D)
7. Dimension B shall not include dambar protrusion/intrusion and solder coverage.
8. Not to scale
9. Dimension in inches
10.Dimensions in (millimeters)
QSOP - Quad Shrink Outline Package
36-Pin
Min Max
36-Pin
Dim
A
Dim
e
Min
Max
.096
.104
.0315 inches (ref)
0.80mm
(2.44)
(2.64)
A
.004
.012
H
.398
.414
1
(0.10)
(0.30)
(10.11) (10.51)
B
.011
.020
L
0.16
.050
(0.28)
(0.51)
(0.40)
(1.27)
C
D
E
.0091
(0.23)
.0125
(0.32)
Q
0°
8°
.598
(15.20) (15.40)
.606
R
.025
(0.63)
.035
(0.89)
.291
(7.40)
.299
(7.60)
ZD
.0335 inches (ref)
0.85
