MT9076
Bit
Name
Functional Description
7
D4YALML D4 Yellow Alarm Latch. This bit is set if a D4 yellow alarm is detected within a 600
millisecond integration period. It is cleared after a read.
6
5
4
D4Y48L
D4 Yellow Alarm (48 milliseconds) Latch. This bit is set if a D4 yellow alarm is detected
within a 48 millisecond integration period. It is cleared after a read.
SECYELL Secondary D4 Yellow Alarm Latch. This bit is set if an alternate D4 (S bit in 12 the frame)
is detected. It is cleared after a read.
ESFYELL ESF Yellow Alarm Latch. This bit is set upon receipt of a ESF yellow alarm. It is cleared
after a read.
3
2
BLUEL
PDVL
Blue Alarm Latch. This bit is set upon receipt of a blue alarm. It is cleared after a read.
Pulse Density Violation Latch. This bit is set upon receipt of a pulse density violation. It is
cleared after a read.
1
0
LLEDL
LLDDL
Line Loopback Enable Detect Latch. This bit is set upon receipt of a line loopback enable
code. It is cleared after a read.
Line Loopback Disable Detect Latch. This bit is set upon receipt of a line loopback disable
code. It is cleared after a read.
Table 66 - Alarm Reporting Latch
(Page 4, Address 12H) (T1)
Bit
Name
Functional Description
7 - 0
FC7 - 0
Framing Bit Counter. This eight bit counter will be incremented for each error in the
received framing pattern. In ESF mode the ESF framing bits are monitored. In D4 mode Fs
bits may be monitored as well as Ft bits. See - Section 15.5 Framing Bit Counter. The count
is only active if the 3VJET is in synchronization.
Table 67 - Framing Bit Counter
(Page 4, Address 13H) (T1)
