Preliminary Information
MT9076
Bit
Name
Functional Description
7
6
1SEC
2SEC
One Second Timer Status. This bit changes state once every 0.5 seconds.
Two Second Timer Status. This bit changes state once every second and is synchronous
with the 1SEC timer.
5
5SEC
- - -
Five Second Timer Status. This bit changes state once every 2.5 seconds and is
synchronous with the 1SEC timer.
4-0
Unused.
Table 53 - Timer Status Word
(Page 3, Address 12H) (T1)
Bit
Name
Functional Description
7
RSLIP
Receive Slip. A change of state (i.e., 1-to-0 or 0-to-1) indicates that a receive controlled
frame slip has occurred.
6
5
RSLPD
RxFRM
Receive Slip Direction. If one, indicates that the last received frame slip resulted in a
repeated frame, i.e., the system clock (C4b) is faster than network clock (E2o). If zero,
indicates that the last received frame slip resulted in a lost frame, i.e., system clock slower
than network clock. Updated on an RSLIP occurance basis.
Receive Frame Delay. The most significant bit of the Receive Slip Buffer Phase Status
Word. If one, the delay through the receive elastic buffer is greater than one frame in length;
if zero, the delay through the receive elastic buffer is less than one frame in length.
4
3
- - -
Unused.
RxFT
Receive Frame Toggle. This bit toggles on the falling edge of RxTS4. It is a Wink pulse.
2-0 RxSBD2-0 Receive Sub Bit Delay. The three least significant bits of the Receive Slip Buffer Phase
Status Word. They indicate the clock, half clock and one eight clock cycle depth of the
phase status word sample point (bits 2, 1,0 respectively).
Table 54 - Most Significant Phase Status Word
(Page 3, Address 13H) (T1)
Bit
Name
Functional Description
7 - 3 RxTS4 - 0 Receive Time Slot. A five bit counter that indicates the number of time slots between the
receive elastic buffer internal write frame boundary and the ST-BUS read frame boundary.
The count is updated every 250 uS.
2 - 0 RxBC2 - 0 Receive Bit Count. A three bit counter that indicates the number of STBUS bit times there
are between the receive elastic buffer internal write frame boundary and the ST-BUS read
frame boundary. The count is updated every 250 uS.
Table 55 - Least Significant Phase Status Word
(Page 3, Address 14H) (T1)
Bit
Name
Functional Description
7 - 0 RxBOM7 - 0 Received Bit Oriented Message. This register contains the eight least significant bits of the
ESF bit oriented message codeword. The contents of this register is updated when a new bit
- oriented message codeword has been detected in 8 out of the last ten codeword positions.
Table 56 - Receive Bit Oriented Message
(Page 3, Address 15H) (T1)
77
