Preliminary Information
MT9076
Bit
Name
Functional Description
7 - 3 RxTS4 - 0 Receive Time Slot. A five bit counter that indicates the number of time slots between
the receive elastic buffer internal write frame boundary and the ST-BUS read frame
boundary. The count is updated every 250 uS.
2 - 0 RxBC2 - 0 Receive Bit Count. A three bit counter that indicates the number of STBUS bit times
there are between the receive elastic buffer internal write frame boundary and the ST-
BUS read frame boundary. The count is updated every 250 uS.
Table 122 - Least Significant Phase Status Word
(Page 3, Address 14H) (E1)
Bit
Name
Functional Description
7
RIU0
Receive International Use Zero. This is the bit which is received on the PCM 30 2048 kbit/
sec. link in bit position one of the frame alignment signal. It is used for the CRC-4 remainder
or for international use.
6 - 0
RFA2-8 Receive Frame Alignment Signal Bits 2 to 8. These bit are received on the PCM 30 2048
kbit/sec. link in bit positions two to eight of frame alignment signal. These bits form the frame
alignment signal and should be 0011011.
Table 123 - Receive Frame Alignment Signal
(Page 3, Address 15H) (E1)
Bit
Name
Functional Description
7
LLOSS LIU Loss of Signal indication. This bit will be high if the received signal is below the
threshold selected by ELOS (page 2, address 10H) for a period of at least 1 msec. This bit
will be low for normal operation.
6-0
- - -
Unused
Table 124 - Receive Signal Status Word
(Page 3, Address 16H) (E1)
113
