Thus, during ambient temperatures, the power
consumed during refresh was unnecessarily high,
because the refresh rate was set to accommodate the
higher temperatures. Setting M4 and M3, allow the
DRAM to accomodate more specific temperature
regions during SELF REFRESH. There are four
temperature settings, which will vary the SELF
REFRESH current according to the selected tempera-
ture. This selectable refresh rate will save power when
the DRAM is operating at normal temperatures.
PARTIAL ARRAY SELF REFRESH
For further power savings during SELF REFRESH, the
Partial Array Self Refresh (PASR) feature allows the con-
troller to select the amount of memory that will be re-
freshed during SELF REFRESH. The refresh options are
all banks (banks 0, 1, 2, and 3); two banks(banks 0 and 1);
and one bank (bank 0). WRITE and READ commands
occur to any bank selected during standard operation,
but only the selected banks in PASR will be refreshed
during SELF REFRESH. It’s important to note that data
in banks 2 and 3 will be lost when the two bank option is
used. Data will be lost in banks 1, 2, and 3 when the one
bank option is used.
