PIC24FJ64GA104 FAMILY
REGISTER 7-17: IPC2: INTERRUPT PRIORITY CONTROL REGISTER 2
U-0
—
R/W-1
R/W-0
R/W-0
U-0
—
R/W-1
R/W-0
R/W-0
U1RXIP2
U1RXIP1
U1RXIP0
SPI1IP2
SPI1IP1
SPI1IP0
bit 15
bit 8
U-0
—
R/W-1
R/W-0
R/W-0
U-0
—
R/W-1
T3IP2
R/W-0
T3IP1
R/W-0
T3IP0
SPF1IP2
SPF1IP1
SPF1IP0
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
-n = Value at POR
bit 15
Unimplemented: Read as ‘0’
bit 14-12
U1RXIP<2:0>: UART1 Receiver Interrupt Priority bits
111= Interrupt is priority 7 (highest priority interrupt)
•
•
•
001= Interrupt is priority 1
000= Interrupt source is disabled
bit 11
Unimplemented: Read as ‘0’
bit 10-8
SPI1IP<2:0>: SPI1 Event Interrupt Priority bits
111= Interrupt is priority 7 (highest priority interrupt)
•
•
•
001= Interrupt is priority 1
000= Interrupt source is disabled
bit 7
Unimplemented: Read as ‘0’
bit 6-4
SPF1IP<2:0>: SPI1 Fault Interrupt Priority bits
111= Interrupt is priority 7 (highest priority interrupt)
•
•
•
001= Interrupt is priority 1
000= Interrupt source is disabled
bit 3
Unimplemented: Read as ‘0’
bit 2-0
T3IP<2:0>: Timer3 Interrupt Priority bits
111= Interrupt is priority 7 (highest priority interrupt)
•
•
•
001= Interrupt is priority 1
000= Interrupt source is disabled
