PIC24FJ64GA104 FAMILY
REGISTER 7-21: IPC6: INTERRUPT PRIORITY CONTROL REGISTER 6
U-0
—
R/W-1
T4IP2
R/W-0
T4IP1
R/W-0
T4IP0
U-0
—
R/W-1
R/W-0
R/W-0
OC4IP2
OC4IP1
OC4IP0
bit 15
bit 8
U-0
—
R/W-1
R/W-0
R/W-0
U-0
—
U-0
—
U-0
—
U-0
—
OC3IP2
OC3IP1
OC3IP0
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
-n = Value at POR
bit 15
Unimplemented: Read as ‘0’
T4IP<2:0>: Timer4 Interrupt Priority bits
bit 14-12
111= Interrupt is priority 7 (highest priority interrupt)
•
•
•
001= Interrupt is priority 1
000= Interrupt source is disabled
bit 11
Unimplemented: Read as ‘0’
bit 10-8
OC4IP<2:0>: Output Compare Channel 4 Interrupt Priority bits
111= Interrupt is priority 7 (highest priority interrupt)
•
•
•
001= Interrupt is priority 1
000= Interrupt source is disabled
bit 7
Unimplemented: Read as ‘0’
bit 6-4
OC3IP<2:0>: Output Compare Channel 3 Interrupt Priority bits
111= Interrupt is priority 7 (highest priority interrupt)
•
•
•
001= Interrupt is priority 1
000= Interrupt source is disabled
bit 3-0
Unimplemented: Read as ‘0’
DS39951C-page 88
2010 Microchip Technology Inc.
