PIC24FJ64GA104 FAMILY
FIGURE 7-1:
PIC24F INTERRUPT VECTOR TABLE
Reset – GOTOInstruction
Reset – GOTOAddress
Reserved
000000h
000002h
000004h
Oscillator Fail Trap Vector
Address Error Trap Vector
Stack Error Trap Vector
Math Error Trap Vector
Reserved
Reserved
Reserved
Interrupt Vector 0
Interrupt Vector 1
—
000014h
—
—
Interrupt Vector 52
Interrupt Vector 53
Interrupt Vector 54
—
00007Ch
00007Eh
000080h
(1)
Interrupt Vector Table (IVT)
—
—
Interrupt Vector 116
Interrupt Vector 117
Reserved
0000FCh
0000FEh
000100h
000102h
Reserved
Reserved
Oscillator Fail Trap Vector
Address Error Trap Vector
Stack Error Trap Vector
Math Error Trap Vector
Reserved
Reserved
Reserved
Interrupt Vector 0
Interrupt Vector 1
—
000114h
—
—
(1)
Alternate Interrupt Vector Table (AIVT)
Interrupt Vector 52
Interrupt Vector 53
Interrupt Vector 54
—
00017Ch
00017Eh
000180h
—
—
Interrupt Vector 116
Interrupt Vector 117
Start of Code
0001FEh
000200h
Note 1: See Table 7-2 for the interrupt vector list.
TABLE 7-1:
TRAP VECTOR DETAILS
IVT Address
Vector Number
AIVT Address
Trap Source
0
1
2
3
4
5
6
7
000004h
000006h
000008h
00000Ah
00000Ch
00000Eh
000010h
000012h
000104h
000106h
000108h
00010Ah
00010Ch
00010Eh
000110h
000112h
Reserved
Oscillator Failure
Address Error
Stack Error
Math Error
Reserved
Reserved
Reserved
DS39951C-page 66
2010 Microchip Technology Inc.
