PIC24FJ64GA104 FAMILY
Pin Diagrams
44-PIN TQFP,
44-Pin QFN(1,3)
SOSCI/C1IND/RP4/CN1/RB4
TDO/PMA8/RA8
RP9/SDA1/CN21/PMD3/RB9
33
32
31
30
29
28
1
RP22/CN18/PMA1/RC6
RP23/CN17/PMA0/RC7
RP24/CN20/PMA5/RC8
RP25/CN19/PMA6/RC9
2
OSCO/CLKO/CN29/RA3
OSCI/CLKI/C1IND/CN30/RA2
VSS
3
4
5
VDD
DISVREG
VCAP/VDDCORE
PGED2/RP10/CN16/PMD2/RB10
PGEC2/RP11/CN15/PMD1/RB11
AN12/RP12/CN14/PMD0/RB12
PIC24FJXXGA104
6
7
8
9
AN8/RP18/PMA2/CN10/RC2
AN7/RP17/CN9/RC1
AN6/RP16/CN8/RC0
AN5/C1INA/RP3/SCL2/CN7/RB3
AN4/C1INB/RP2/SDA2/CN6/RB2
27
26
25
24
23
10
11
AN11/C1INC/RP13/PMRD/REFO/CN13/RB13
Legend:
RPn represents remappable peripheral pins.
Note 1: Gray shading indicates 5.5V tolerant input pins.
2: Alternative multiplexing for SDA1 and SCL1 when the I2C1SEL bit is set.
3: The back pad on QFN devices should be connected to VSS.
DS39951C-page 6
2010 Microchip Technology Inc.
