PIC24FJ64GA104 FAMILY
The maximum baud rate (BRGH = 0) possible is
FCY/16 (for UxBRG = 0) and the minimum baud rate
17.1 UART Baud Rate Generator (BRG)
The UART module includes a dedicated 16-bit Baud
Rate Generator. The UxBRG register controls the
period of a free-running, 16-bit timer. Equation 17-1
shows the formula for computation of the baud rate
with BRGH = 0.
possible is FCY/(16 * 65536).
Equation 17-2 shows the formula for computation of
the baud rate with BRGH = 1.
EQUATION 17-2: UART BAUD RATE WITH
BRGH = 1(1,2)
EQUATION 17-1: UART BAUD RATE WITH
BRGH = 0(1,2)
FCY
Baud Rate =
4 • (UxBRG + 1)
FCY
Baud Rate =
16 • (UxBRG + 1)
FCY
– 1
UxBRG =
4 • Baud Rate
FCY
16 • Baud Rate
– 1
UxBRG =
Note 1: FCY denotes the instruction cycle clock
frequency.
Note 1: FCY denotes the instruction cycle clock
frequency (FOSC/2).
2: Based on FCY = FOSC/2, Doze mode
and PLL are disabled.
2: Based on FCY = FOSC/2, Doze mode
and PLL are disabled.
The maximum baud rate (BRGH = 1) possible is FCY/4
(for UxBRG = 0) and the minimum baud rate possible
is FCY/(4 * 65536).
Example 17-1 shows the calculation of the baud rate
error for the following conditions:
Writing a new value to the UxBRG register causes the
BRG timer to be reset (cleared). This ensures the BRG
does not wait for a timer overflow before generating the
new baud rate.
• FCY = 4 MHz
• Desired Baud Rate = 9600
EXAMPLE 17-1:
BAUD RATE ERROR CALCULATION (BRGH = 0)(1)
Desired Baud Rate = FCY/(16 (UxBRG + 1))
Solving for UxBRG Value:
UxBRG
UxBRG
UxBRG
= ((FCY/Desired Baud Rate)/16) – 1
= ((4000000/9600)/16) – 1
= 25
Calculated Baud Rate = 4000000/(16 (25 + 1))
= 9615
Error
= (Calculated Baud Rate – Desired Baud Rate)
Desired Baud Rate
= (9615 – 9600)/9600
= 0.16%
Note 1: Based on FCY = FOSC/2, Doze mode and PLL are disabled.
DS39951C-page 184
