PIC18F2480/2580/4480/4580
IORLW
Inclusive OR Literal with W
IORWF
Inclusive OR W with f
Syntax:
IORLW
k
Syntax:
IORWF f {,d {,a}}
Operands:
Operation:
Status Affected:
Encoding:
Description:
0 ≤ k ≤ 255
(W) .OR. k → W
N, Z
Operands:
0 ≤ f ≤ 255
d ∈ [0,1]
a ∈ [0,1]
Operation:
(W) .OR. (f) → dest
0000
1001
kkkk
kkkk
Status Affected:
Encoding:
N, Z
The contents of W are ORed with the
eight-bit literal ‘k’. The result is placed
in W.
0001
00da
ffff
ffff
Description:
Inclusive OR W with register ‘f’. If ‘d’ is
‘0’, the result is placed in W. If ‘d’ is ‘1’,
the result is placed back in register ‘f’.
Words:
Cycles:
1
1
If ‘a’ is ‘0’, the Access Bank is selected.
If ‘a’ is ‘1’, the BSR is used to select the
GPR bank.
Q Cycle Activity:
Q1
Q2
Q3
Q4
If ‘a’ is ‘0’ and the extended instruction
set is enabled, this instruction operates
in Indexed Literal Offset Addressing
mode whenever f ≤ 95 (5Fh). See
Section 26.2.3 “Byte-Oriented and
Bit-Oriented Instructions in Indexed
Literal Offset Mode” for details.
Decode
Read
literal ‘k’
Process
Data
Write to W
Example:
IORLW
35h
Before Instruction
W
=
9Ah
BFh
After Instruction
Words:
Cycles:
1
1
W
=
Q Cycle Activity:
Q1
Q2
Q3
Q4
Decode
Read
register ‘f’
Process
Data
Write to
destination
Example:
IORWF RESULT, 0, 1
Before Instruction
RESULT =
13h
91h
W
=
After Instruction
RESULT =
13h
93h
W
=
DS39637D-page 390
© 2009 Microchip Technology Inc.
