PIC18F2480/2580/4480/4580
LFSR
Load FSR
MOVF
Move f
Syntax:
LFSR f, k
Syntax:
MOVF f {,d {,a}}
Operands:
0 ≤ f ≤ 2
0 ≤ k ≤ 4095
Operands:
0 ≤ f ≤ 255
d ∈ [0,1]
a ∈ [0,1]
Operation:
k → FSRf
Operation:
f → dest
Status Affected:
Encoding:
None
Status Affected:
Encoding:
N, Z
1110
1111
1110
0000
00ff
k kkk
k kkk
11
kkkk
0101
00da
ffff
ffff
7
Description:
The 12-bit literal ‘k’ is loaded into the
file select register pointed to by ‘f’.
Description:
The contents of register ‘f’ are moved to
a destination dependent upon the
status of ‘d’. If ‘d’ is ‘0’, the result is
placed in W. If ‘d’ is ‘1’, the result is
placed back in register ‘f’. Location ‘f’
can be anywhere in the 256-byte bank.
Words:
Cycles:
2
2
Q Cycle Activity:
Q1
If ‘a’ is ‘0’, the Access Bank is selected.
If ‘a’ is ‘1’, the BSR is used to select the
GPR bank.
Q2
Q3
Q4
Decode
Read literal
‘k’ MSB
Process
Data
Write
literal ‘k’
MSB to
FSRfH
If ‘a’ is ‘0’ and the extended instruction
set is enabled, this instruction operates
in Indexed Literal Offset Addressing
mode whenever f ≤ 95 (5Fh). See
Section 26.2.3 “Byte-Oriented and
Bit-Oriented Instructions in Indexed
Literal Offset Mode” for details.
Decode
Read literal
‘k’ LSB
Process
Data
Write literal
‘k’ to FSRfL
Example:
LFSR 2, 3ABh
After Instruction
Words:
Cycles:
1
1
FSR2H
FSR2L
=
=
03h
ABh
Q Cycle Activity:
Q1
Q2
Q3
Q4
Decode
Read
register ‘f’
Process
Data
Write W
Example:
MOVF
REG, 0, 0
Before Instruction
REG
W
=
=
22h
FFh
After Instruction
REG
W
=
=
22h
22h
© 2009 Microchip Technology Inc.
DS39637D-page 391
