PIC18F2480/2580/4480/4580
BZ
Branch if Zero
CALL
Subroutine Call
Syntax:
BZ
n
Syntax:
CALL k {,s}
Operands:
Operation:
-128 ≤ n ≤ 127
Operands:
0 ≤ k ≤ 1048575
s ∈ [0,1]
if Zero bit is ‘1’,
(PC) + 2 + 2n → PC
Operation:
(PC) + 4 → TOS,
k → PC<20:1>;
if s = 1,
Status Affected:
Encoding:
None
1110
0000
nnnn
nnnn
(W) → WS,
(STATUS) → STATUSS,
(BSR) → BSRS
Description:
If the Zero bit is ‘1’, then the program
will branch.
The 2’s complement number ‘2n’ is
added to the PC. Since the PC will have
incremented to fetch the next
instruction, the new address will be
PC + 2 + 2n. This instruction is then a
two-cycle instruction.
Status Affected:
None
Encoding:
1st word (k<7:0>)
2nd word(k<19:8>)
1110
1111
110s
k kkk
kkkk
kkkk
7
0
8
k
kkk kkkk
19
Description:
Subroutine call of entire 2-Mbyte
memory range. First, return address
(PC + 4) is pushed onto the return
stack. If ‘s’ = 1, the W, STATUS and
Words:
Cycles:
1
1(2)
Q Cycle Activity:
If Jump:
Q1
BSR registers are also pushed into their
respective shadow registers, WS,
STATUSS and BSRS. If ‘s’ = 0, no
update occurs. Then, the 20-bit value ‘k’
is loaded into PC<20:1>. CALLis a two-
cycle instruction.
Q2
Q3
Q4
Decode
Read literal
‘n’
Process
Data
Write to PC
No
operation
No
operation
No
operation
No
operation
Words:
Cycles:
2
2
If No Jump:
Q1
Q2
Q3
Q4
Q Cycle Activity:
Q1
Decode
Read literal
‘n’
Process
Data
No
operation
Q2
Q3
Q4
Decode
Read literal Push PC to Read literal
‘k’<7:0>,
stack
‘k’<19:8>,
Write to PC
Example:
HERE
BZ Jump
No
operation
No
operation
No
operation
No
operation
Before Instruction
PC
=
address (HERE)
After Instruction
If Zero
PC
If Zero
PC
=
=
=
=
1;
Example:
HERE
CALL THERE,1
address (Jump)
Before Instruction
PC
After Instruction
0;
address (HERE + 2)
=
address (HERE)
PC
=
address (THERE)
TOS
WS
=
=
=
address (HERE + 4)
W
BSR
STATUS
BSRS
STATUSS=
DS39637D-page 382
