PIC18F2480/2580/4480/4580
BRA
Unconditional Branch
BSF
Bit Set f
Syntax:
BRA
n
Syntax:
BSF f, b {,a}
Operands:
Operation:
Status Affected:
Encoding:
Description:
-1024 ≤ n ≤ 1023
(PC) + 2 + 2n → PC
None
Operands:
0 ≤ f ≤ 255
0 ≤ b ≤ 7
a ∈ [0,1]
Operation:
1 → f<b>
1101
0nnn
nnnn
nnnn
Status Affected:
Encoding:
None
Add the 2’s complement number ‘2n’ to
the PC. Since the PC will have
incremented to fetch the next
instruction, the new address will be
PC + 2 + 2n. This instruction is a
two-cycle instruction.
1000
bbba
ffff
ffff
Description:
Bit ‘b’ in register ‘f’ is set.
If ‘a’ is ‘0’, the Access Bank is selected.
If ‘a’ is ‘1’, the BSR is used to select the
GPR bank.
Words:
Cycles:
1
2
If ‘a’ is ‘0’ and the extended instruction
set is enabled, this instruction operates
in Indexed Literal Offset Addressing
mode whenever f ≤ 95 (5Fh). See
Section 26.2.3 “Byte-Oriented and
Bit-Oriented Instructions in Indexed
Literal Offset Mode” for details.
Q Cycle Activity:
Q1
Q2
Q3
Q4
Decode
Read literal
‘n’
Process
Data
Write to PC
Words:
Cycles:
1
1
No
operation
No
operation
No
operation
No
operation
Q Cycle Activity:
Q1
Example:
HERE
BRA Jump
Q2
Q3
Q4
Decode
Read
register ‘f’
Process
Data
Write
register ‘f’
Before Instruction
PC
=
=
address (HERE)
address (Jump)
After Instruction
PC
Example:
BSF
FLAG_REG, 7, 1
0Ah
8Ah
Before Instruction
FLAG_REG
After Instruction
FLAG_REG
=
=
© 2009 Microchip Technology Inc.
DS39637D-page 379
