PIC18F2480/2580/4480/4580
19.2.2
EUSART ASYNCHRONOUS
RECEIVER
19.2.3
SETTING UP 9-BIT MODE WITH
ADDRESS DETECT
The receiver block diagram is shown in Figure 19-6.
The data is received on the RX pin and drives the data
recovery block. The data recovery block is actually a
high-speed shifter operating at x16 times the baud rate,
whereas the main receive serial shifter operates at the
bit rate or at FOSC. This mode would typically be used
in RS-232 systems.
This mode would typically be used in RS-485 systems.
To set up an Asynchronous Reception with Address
Detect Enable:
1. Initialize the SPBRGH:SPBRG registers for the
appropriate baud rate. Set or clear the BRGH
and BRG16 bits, as required, to achieve the
desired baud rate.
To set up an Asynchronous Reception:
2. Enable the asynchronous serial port by clearing
the SYNC bit and setting the SPEN bit.
1. Initialize the SPBRGH:SPBRG registers for the
appropriate baud rate. Set or clear the BRGH
and BRG16 bits, as required, to achieve the
desired baud rate.
3. If interrupts are required, set the RCEN bit and
select the desired priority level with the RCIP bit.
4. Set the RX9 bit to enable 9-bit reception.
5. Set the ADDEN bit to enable address detect.
6. Enable reception by setting the CREN bit.
2. Enable the asynchronous serial port by clearing
bit, SYNC, and setting bit, SPEN.
3. If interrupts are desired, set enable bit, RCIE.
4. If 9-bit reception is desired, set bit, RX9.
5. Enable the reception by setting bit, CREN.
7. The RCIF bit will be set when reception is
complete. The interrupt will be Acknowledged if
the RCIE and GIE bits are set.
6. Flag bit, RCIF, will be set when reception is com-
plete and an interrupt will be generated if enable
bit, RCIE, was set.
8. Read the RCSTA register to determine if any
error occurred during reception, as well as read
bit 9 of data (if applicable).
7. Read the RCSTA register to get the 9th bit (if
enabled) and determine if any error occurred
during reception.
9. Read RCREG to determine if the device is being
addressed.
10. If any error occurred, clear the CREN bit.
8. Read the 8-bit received data by reading the
RCREG register.
11. If the device has been addressed, clear the
ADDEN bit to allow all received data into the
receive buffer and interrupt the CPU.
9. If any error occurred, clear the error by clearing
enable bit, CREN.
10. If using interrupts, ensure that the GIE and PEIE
bits in the INTCON register (INTCON<7:6>) are
set.
FIGURE 19-6:
EUSART RECEIVE BLOCK DIAGRAM
CREN
OERR
FERR
x64 Baud Rate CLK
SPBRGH SPBRG
÷ 64
or
RSR Register
• • •
MSb
Stop
LSb
Start
BRG16
÷ 16
(8)
7
1
0
or
÷ 4
Baud Rate Generator
RX9
Pin Buffer
and Control
Data
Recovery
RX
RX9D
RCREG Register
FIFO
SPEN
8
Interrupt
RCIF
RCIE
Data Bus
DS39637D-page 244
© 2009 Microchip Technology Inc.
