PIC18CXX2
BTFSC
Bit Test File, Skip if Clear
BTFSS
Bit Test File, Skip if Set
Syntax:
[ label ] BTFSC f,b,a
Syntax:
[ label ] BTFSS f,b,a
Operands:
0 ≤ f ≤ 255
0 ≤ b ≤ 7
Operands:
0 ≤ f ≤ 255
0 ≤ b < 7
a
[0,1]
a
[0,1]
Operation:
skip if (f<b>) = 0
None
Operation:
skip if (f<b>) = 1
None
Status Affected:
Encoding:
Status Affected:
Encoding:
1011
bbba
ffff
ffff
1010
bbba
ffff
ffff
Description:
If bit 'b' in register ’f' is 0, then the
next instruction is skipped.
Description:
If bit 'b' in register 'f' is 1 then the next
instruction is skipped.
If bit 'b' is 0, then the next instruction
fetched during the current instruction
execution is discarded, and a NOPis
executed instead, making this a two-
cycle instruction. If ’a’ is 0, the
Access Bank will be selected, over-
riding the BSR value. If ’a’ = 1, then
the bank will be selected as per the
BSR value (default).
If bit 'b' is 1, then the next instruction
fetched during the current instruc-
tion execution, is discarded and an
NOPis executed instead, making this
a two-cycle instruction. If ’a’ is 0, the
Access Bank will be selected, over-
riding the BSR value. If ’a’ = 1, then
the bank will be selected as per the
BSR value (default).
Words:
Cycles:
1
Words:
Cycles:
1
1(2)
1(2)
Note: 3 cycles if skip and followed
by a 2-word instruction
Note: 3 cycles if skip and followed
by a 2-word instruction
Q Cycle Activity:
Q1
Q Cycle Activity:
Q1
Q2
Q3
Q4
Q2
Q3
Q4
Decode
Read
Process Data
No
Decode
Read
Process Data
No
register ’f’
operation
register ’f’
operation
If skip:
Q1
If skip:
Q1
Q2
Q3
Q4
Q2
Q3
Q4
No
No
No
No
No
No
No
No
operation
operation
operation
operation
operation
operation
operation
operation
If skip and followed by 2-word instruction:
If skip and followed by 2-word instruction:
Q1
Q2
Q3
Q4
Q1
Q2
Q3
Q4
No
No
No
No
No
No
No
No
operation
operation
operation
operation
operation
operation
operation
operation
No
No
No
No
No
No
No
No
operation
operation
operation
operation
operation
operation
operation
operation
HERE
FALSE
TRUE
BTFSC
:
:
FLAG, 1, 0
HERE
FALSE
TRUE
BTFSS
:
:
FLAG, 1, 0
Example:
Example:
Before Instruction
Before Instruction
PC
=
address (HERE)
PC
=
address (HERE)
After Instruction
After Instruction
If FLAG<1>
=
=
=
=
0;
If FLAG<1>
=
=
=
=
0;
PC
If FLAG<1>
PC
address (TRUE)
1;
PC
If FLAG<1>
PC
address (FALSE)
1;
address (FALSE)
address (TRUE)
DS39026B-page 204
Preliminary
7/99 Microchip Technology Inc.
