PIC18F6525/6621/8525/8621
9.3
PIE Registers
The PIE registers contain the individual enable bits for
the peripheral interrupts. Due to the number of
peripheral interrupt sources, there are three Peripheral
Interrupt Enable registers (PIE1, PIE2 and PIE3).
When the IPEN bit (RCON<7>) is ‘0’, the PEIE bit must
be set to enable any of these peripheral interrupts.
REGISTER 9-7:
PIE1: PERIPHERAL INTERRUPT ENABLE REGISTER 1
R/W-0
PSPIE(1)
bit 7
R/W-0
ADIE
R/W-0
RC1IE
R/W-0
TX1IE
R/W-0
SSPIE
R/W-0
R/W-0
R/W-0
TMR1IE
bit 0
CCP1IE
TMR2IE
bit 7
PSPIE: Parallel Slave Port Read/Write Interrupt Enable bit(1)
1= Enables the PSP read/write interrupt
0= Disables the PSP read/write interrupt
Note:
Enabled only in Microcontroller mode for PIC18F8525/8621 devices.
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
ADIE: A/D Converter Interrupt Enable bit
1= Enables the A/D interrupt
0= Disables the A/D interrupt
RC1IE: USART1 Receive Interrupt Enable bit
1= Enables the USART1 receive interrupt
0= Disables the USART1 receive interrupt
TX1IE: USART1 Transmit Interrupt Enable bit
1= Enables the USART1 transmit interrupt
0= Disables the USART1 transmit interrupt
SSPIE: Master Synchronous Serial Port Interrupt Enable bit
1= Enables the MSSP interrupt
0= Disables the MSSP interrupt
CCP1IE: ECCP1 Interrupt Enable bit
1= Enables the ECCP1 interrupt
0= Disables the ECCP1 interrupt
TMR2IE: TMR2 to PR2 Match Interrupt Enable bit
1= Enables the TMR2 to PR2 match interrupt
0= Disables the TMR2 to PR2 match interrupt
TMR1IE: TMR1 Overflow Interrupt Enable bit
1= Enables the TMR1 overflow interrupt
0= Disables the TMR1 overflow interrupt
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
2005 Microchip Technology Inc.
DS39612B-page 95
