15.2.1.2 SLAVE RECEPTION
15.2.1.3
SLAVE TRANSMISSION
When the R/W bit of the address byte is clear and an
address match occurs, the R/W bit of the SSPSTAT
register is cleared. The received address is loaded into
the SSPBUF register.
When the R/W bit of the incoming address byte is set
and an address match occurs, the R/W bit of the
SSPSTAT register is set. The received address is
loaded into the SSPBUF register. The ACK pulse will
be sent on the ninth bit, and the SCLpin is held low.The
transmit data must be loaded into the SSPBUF register,
which also loads the SSPSR register. Then SCL pin
should be enabled by setting bit CKP (SSPCON1<4>).
The master must monitor the SCL pin prior to asserting
another clock pulse. The slave devices may be holding
off the master by stretching the clock. The eight data
bits are shifted out on the falling edge of the SCL input.
This ensures that the SDA signal is valid during the
SCL high time (Figure 15-16).
When the address byte overflow condition exists, then
no acknowledge (ACK) pulse is given. An overflow con-
dition is defined as either bit BF (SSPSTAT<0>) is set
or bit SSPOV (SSPCON1<6>) is set.
An SSP interrupt is generated for each data transfer
byte. Flag bit SSPIF (PIR2<7>) must be cleared in soft-
ware. The SSPSTAT register is used to determine the
status of the byte.
Note: The SSPBUF will be loaded if the SSPOV
bit = 1 and the BF flag = 0. If a read of the
SSPBUF was performed, but the user did
not clear the state of the SSPOV bit before
the next receive occured. The ACK is not
sent and the SSPBUF is updated.
2
FIGURE 15-15: I C WAVEFORMS FOR RECEPTION (7-BIT ADDRESS)
Receiving Address
A7 A6 A5 A4
R/W=0
Receiving Data
Receiving Data
ACK
ACK
9
ACK
SDA
SCL
A3 A2 A1
D5
D2
D0
8
D5
D2
D0
8
D7 D6
D4 D3
D7 D6
D4 D3
D1
7
D1
7
3
7
1
2
4
9
5
4
3
6
9
5
6
1
2
3
6
1
2
4
8
5
P
S
SSPIF (PIR2<7>)
Bus Master
terminates
transfer
BF (SSPSTAT<0>)
Cleared in software
SSPBUF register is read
SSPOV (SSPCON1<6>)
Bit SSPOV is set because the SSPBUF register is still full.
ACK is not sent.
2
FIGURE 15-16: I C WAVEFORMS FOR TRANSMISSION (7-BIT ADDRESS)
Receiving Address
R/W = 1
ACK
Transmitting Data
ACK
SDA
SCL
A7 A6 A5 A4 A3 A2 A1
D7 D6 D5 D4 D3 D2 D1 D0
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
S
P
SCL held low
while CPU
responds to SSPIF
Data in
sampled
SSPIF (PIR1<3>)
BF (SSPSTAT<0>)
cleared in software
SSPBUF is written in software
From SSP interrupt
service routine
CKP (SSPCON1<4>)
Set bit after writing to SSPBUF
(the SSPBUF must be written-to
before the CKP bit can be set)
