PIC16F/LF1946/47
22.0 CAPTURE/COMPARE/PWM
MODULES
Note 1: In devices with more than one CCP
module, it is very important to pay close
attention to the register names used. A
number placed after the module acronym
is used to distinguish between separate
modules. For example, the CCP1CON
and CCP2CON control the same
operational aspects of two completely
different CCP modules.
The Capture/Compare/PWM module is a peripheral
which allows the user to time and control different
events, and to generate Pulse-Width Modulation
(PWM) signals. In Capture mode, the peripheral allows
the timing of the duration of an event. The Compare
mode allows the user to trigger an external event when
a predetermined amount of time has expired. The
PWM mode can generate Pulse-Width Modulated
signals of varying frequency and duty cycle.
2: Throughout
this
section,
generic
references to a CCP module in any of its
operating modes may be interpreted as
being equally applicable to ECCP1,
ECCP2, ECCP3, CCP4 and CCP5.
Register names, module signals, I/O pins,
and bit names may use the generic
designator ‘x’ to indicate the use of a
numeral to distinguish a particular module,
when required.
This family of devices contains three Enhanced
Capture/Compare/PWM modules (ECCP1, ECCP2 and
ECCP3) and two standard Capture/Compare/PWM
modules (CCP4 and CCP5).
The Capture and Compare functions are identical for all
five CCP modules (ECCP1, ECCP2, ECCP3, CCP4
and CCP5). The only differences between CCP
modules are in the Pulse-Width Modulation (PWM)
function. The standard PWM function is identical in
modules, CCP4 and CCP5. In CCP modules ECCP1,
ECCP2 and ECCP3, the Enhanced PWM function has
slight variations from one another. Full-Bridge ECCP
modules have four available I/O pins while Half-Bridge
ECCP modules only have two available I/O pins. See
Table 22-1 for more information.
TABLE 22-1: PWM RESOURCES
Device Name
ECCP1
Enhanced PWM Enhanced PWM Enhanced PWM
Full-Bridge Full-Bridge Full-Bridge
ECCP2
ECCP3
CCP4
CCP5
PIC16F/LF1946/47
Standard PWM
Standard PWM
2010 Microchip Technology Inc.
Preliminary
DS41414A-page 207
