9-22. Block Erase (BE)
The Block Erase (BE) instruction is for erasing the data of the chosen block to be "1". The instruction is used for
64K-byte block erase operation. A Write Enable (WREN) instruction must be executed to set the Write Enable Latch
(WEL) bit before sending the Block Erase (BE). Any address of the block (Please refer to "Table 4. Memory Organi-
zation") is a valid address for Block Erase (BE) instruction. The CS# must go high exactly at the byte boundary (the
least significant bit of address byte been latched-in); otherwise, the instruction will be rejected and not executed.
The sequence of issuing BE instruction is: CS# goes low→ sending BE instruction code→ 3-byte address on SI→
CS# goes high.
Both SPI (8 clocks) and QPI (2 clocks) command cycle can accept by this instruction. The SIO[3:1] are don't care
when during SPI mode.
The self-timed Block Erase Cycle time (tBE) is initiated as soon as Chip Select (CS#) goes high. The Write in
Progress (WIP) bit still can be checked while the Block Erase cycle is in progress. The WIP sets during the tBE
timing, and clears when Block Erase Cycle is completed, and the Write Enable Latch (WEL) bit is reset. If the Block
is protected by BP bits (WPSEL=0; Block Protect Mode) or SPB/DPB (WPSEL=1; Advanced Sector Protect Mode),
the Block Erase (BE) instruction will not be executed on the block.
Figure 48. Block Erase (BE) Sequence (SPI Mode)
CS#
0
1
2
3
4
5
6
7
8
9
29 30 31
Mode 3
Mode 0
SCLK
Command
D8h
24-Bit Address
A23 A22
A2 A1 A0
SI
MSB
Figure 49. Block Erase (BE) Sequence (QPI Mode)
CS#
Mode 3
Mode 0
0
1
2
3
4
5
6
7
SCLK
24-Bit Address
Command
SIO[3:0]
D8h A5 A4 A3 A2 A1 A0
MSB
