Ribbon Cable Interconnect Solutions
Board-to-Board Vertical Headers, Double Row, .050 x .050
[1.27 x 1.27] Centerline
.050
[1.27]
.225
[5.71]
.050
[1.27]
A
.2255
[5.728]
For .250 [6.35] Mated Height
.050
[1.27]
.030
[0.76]
A
For .320 [8.13] Mated Height
.2975
[7.557]
.050
[1.27]
.030
[0.76]
A
.3675
[9.335]
For .390 [9.91] Mated Height
.050
[1.27]
.030
[0.76]
Material and Finish
Related Product Data
Technical Documents — page 29
Product Specification 108-1332
Application Specification
114-7010
Housing—Glass-filled thermoplastic,
black, 94V-0 rated
Contacts—Copper alloy; duplex plated
.000030 [0.00076] gold in mating area,
.000150 [0.00381] tin on solder tail,
with entire contact underplated .000050
[0.00127] nickel
Mating Receptacles — pages 20 and
26 (without latch only)
PC Board Layouts — page 22
Performance Specifications — page
29
Packaging — Tube or Tape and Reel
Holddown—Copper alloy; plated
.000150 [0.00381] tin over .000050
[0.00127] nickel
Header Part Numbers
.250 [6.35] Mated Height
Tape & Reel*
.320 [8.13] Mated Height
.390 [9.91] Mated Height
Tubes
Hold Down No Hold Down
No. of
Pos.
Dimension
A
Tubes
Tubes
Tape & Reel*
Tape & Reel*
Hold Down No Hold Down
10
20
30
40
50
60
70
80
90
100
.372 [9.44] 5-104655-1
.622 [15.79] 5-104655-3
.872 [22.14] 5-104655-4
1.122 [28.49] 5-104655-5
1.372 [34.84] 5-104655-6
1.622 [41.19] 5-104655-7
1.872 [47.54] 5-104655-8
2.122 [53.89] 5-104655-9
5-147381-1
5-147381-2
5-147381-3
5-147381-4
5-147381-5
5-147381-6
5-147381-7
5-147381-8
—
5-147121-1
5-104656-1
5-104656-2
5-104656-3
5-104656-4
5-104656-5
5-104656-6
5-104656-7
5-104656-8
5-104656-9
6-104656-0
5-147382-1
5-147382-2
5-147382-3
5-147382-4
5-147382-5
5-147382-6
5-147382-7
5-147382-8
—
5-104693-1
5-104693-2
5-104693-3
5-104693-4
5-104693-5
5-104693-6
5-104693-7
5-104693-8
5-104693-9
6-104693-0
—
5-147383-1
5-147383-2
5-147383-3
5-147383-4
5-147383-5
5-147383-6
5-147383-7
5-147383-8
—
5-147121-2
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
2.372 [60.24]
—
2.622 [66.59] 6-104655-1
5-147381-9
5-147382-9
5-147503-1
5-147383-9
*Parts packaged in tape and reel have vacuum pick and place cover.
See PC Board Layout on page 22.
Note: All part numbers are RoHS compliant.
