METRIC
Dimensions are
millimeters over inches
Ribbon Cable Interconnect Solutions
2.0 mm [.079] Receptacle Connectors,
Non-Polarized and Center Polarized Bar
Material and Finish
A
Housing and Termination Cover —
UL 94V-0 rated polyester, black
5.16
Contacts — Beryllium copper, duplex
plated 0.00076 [.000030] min. gold on
mating end, 0.00013 [.000005] min.
gold on termination end, all underplated
0.00127 [.000050] min. nickel
[.203]
Optional Center Polarizer Bar
Note: Accepts 0.08-0.09mm2 [28 AWG]
ribbon cable, PVC insulated 1.00 [.039]
pitch. See Application Specification for
details.
1.54
[.061]
10.24
[.403]
Technical Documents
Product Specification
108-1372
5.00
[.197]
4.000
[.1575]
Position Number
1 Indicator
Application Specification
114-40038
B
Mateable Connectors — pages 9
and 12, or see Application Specification
for header requirements
Position Number 1
0.05
1.90
[.075
.002
]
2.00
[.079]
Typ.
Accessories
8.48
[.334]
Pull Loops — page 66
Keying Plugs — page 64
Strain Relief — page 68
2.00
[.079]
Typ.
Terminated View,Typical
Dimensions
No. of
Positions
Center
Polarized
Non-Polarized
A
B
13.18
8.41
8
3-111623-0
1-111623-8
3-111623-1
1-111623-9
2-111623-0
2-111623-1
2-111623-9
2-111623-7
2-111623-2
2-111623-3
2-111623-8
2-111623-4
2-111623-5
2-111623-6
2-111626-4
1-111626-7
—
.519
.331
15.16
.597
10.41
.410
10
12
14
16
20
22
24
26
30
34
40
44
50
17.15
.675
12.40
.488
19.18
.755
14.40
.567
1-111626-8
2-111626-5
1-111626-9
—
21.18
.834
16.41
.646
25.17
.991
20.40
803
27.18
1.070
22.40
.882
29.18
1.149
24.41
.961
2-111626-6
2-111626-7
—
31.17
1.227
26.42
1.040
35.18
1.385
30.40
1.197
39.17
1.542
34.42
1.355
2-111626-0
2-111626-1
2-111626-2
2-111626-3
45.19
1.779
40.41
1.591
49.17
1.936
44.40
1.748
55.17
2.172
50.39
1.984
Note: All part numbers are RoHS compliant.
17
Catalog 82012
Revised 4-12
Dimensions are shown for
Dimensions are in inches
