Ribbon Cable Interconnect Solutions
Cable-to-Board Connectors
Product Facts
I Double-row receptacle
connectors provide cable-
to-board connection
capabilities for vertical
headers (non-latching) and
right-angle headers
(latching and non-latching)
I IDC (Insulation
Displacement Crimp) mass
termination of solid or
stranded round conductor
.050 [1.27] centerline
ribbon cable with PVC or
polyethylene insulation
I Accommodates ribbon cable
conductor sizes of 28 AWG
[0.08-0.09 mm2] and 30
AWG [0.05 mm2] and
insulation diameters up to
.036 [0.91] maximum
I Reliable single beam
receptacle contact design
I Duplex plated receptacle
contacts; gold plated in
mating area, tin in
These double-row cable
connectors, with a .050 x
.050 [1.27 x 1.27] centerline
contact spacing, provide
cable-to-board connection
capabilities for the
stranded round conductor
mounted right-angle header.
termination area
ribbon cable with conductor The cable connector without
I Terminating covers (sold
separately) provide both
strain relief and protection
to the termination area
I Sizes of 10, 20, 30, 40, 50,
60, 70, 80 and 100 positions
I Connectors available with or connectors without a latch
without metal latch
I Connectors without latches
are polarized to help
prevent mismating
sizes of 28 AWG [0.08-0.09
mm2] and 30 AWG [0.05
mm2] and a maximum
insulation diameter of .036
[0.91]. During termination,
the terminating covers,
which must be purchased
separately, assist in guiding
the wire into the IDC
contacts, then provide
strain relief when fully
seated. Actual termination
is accomplished with the TE
manual tooling shown on
page 28.
a metal latch features
polarization to help prevent
mismating. All connectors
are available in sizes
ranging from 10 through
100 positions (in 10 position
increments).
AMPMODU 50/50 Grid
Connector System. Cable
will mate with the vertical
headers (page 21), while
cable connectors with or
without a latch can be used
to mate with the right-angle
headers (page 24).
I Recognized under the
Component Program of
Underwriters
The cable connectors
feature reliable single-
beam IDC (insulation
displacement crimp)
contacts which are duplex
plated with .000030
[0.00076] gold. These
contacts can be mass
terminated to either solid or
Laboratories Inc.,
File No. E28476
R
The latching version of
the cable connector is
equipped with a metal latch
which provides positive
retention of the receptacle
cable connector when
mated with a surface-
I Certified by Canadian
Standards
R
Association
File No. LR7189
25
Catalog 82012
Revised 4-12
Dimensions are shown for
Dimensions are in inches
Canada: +1 (905) 475-6222
UK: +44 (0) 800-267666
reference purposes only.
and millimeters unless
otherwise specified.
