Ribbon Cable Interconnect Solutions
Board-to-Board Right-Angle Headers
Product Facts
I Surface-mount products for
right-angle board-to-board
and cable-to-board
applications
I Double-row, right-angle
shrouded headers
I High density .050 x .050
[1.27 x 1.27] centerline grid
I Latching and non-latching
versions available
I Non-protrusive metallic
holddowns
I Metallic tabs, when
soldered to PC board pad,
provide added mechanical
support
I Duplex plated post contacts;
gold plated on mating area,
tin plated on tails
I Compatible with standard
surface-mount processing
(VPR and IR)
I Standoffs on header
housings allow for drainage
of processing fluids
I All headers are polarized
I Sizes of 10, 20, 30, 40, 50,
60, 70, 80 and 100 positions
AMPMODU 50/50 Grid
Right-Angle Headers will
accommodate a variety of
high density packaging
applications; right-angle
board-to-board applications
when mated with vertical
receptacles (page 20) and
right-angle cable-to-board
applications when mated
with cable connectors
(page 26). The small
design as those used in the
vertical headers (page 21)
and receptacles (page 20).
There are also metallic tabs
that are soldered to the sur-
faces of the PC board pads
for added support.
I Recognized under the
Component Program of
Underwriters
AMPMODU 50/50 Grid
Right-Angle Headers are
available in double-row, in
either latching or non-
latching versions, and in
sizes ranging from 10
through 100 positions (in 10
position increments). The
latching version provides
positive retention when
mated with the latching
cable connector (page 26).
All headers feature polariza-
tion to help prevent mis-
alignment during mating.
R
Laboratories Inc.,
File No. E28476
I Certified by Canadian
Standards
.050 x .050 [1.27 x 1.27]
centerline contact spacing
allows efficient use of the
PC board area.
Association
R
File No. LR7189
Mechanical support of the
headers to the PC board is
provided by non-protrusive
metallic holddowns
designed for .062 [1.57] or
thicker PC boards. These
holddowns are of the same
23
Catalog 82012
Revised 4-12
