Ribbon Cable Interconnect Solutions
Board-to-Board Right-Angle Headers, Double Row, .050 x .050
[1.27 x 1.27] Centerline
Non-Latching Header
A
.050
[1.27]
Typ.
.050
[1.27]
.213
[5.41]
Latching Header
.352
[8.94]
.050
[1.27]
.430
[10.92]
.029
[0.74]
Typ
.047
[1.19]
Plated-Thru Hole
(2 Plc)
Dia
Material and Finish
.065
[1.65]
Typ.
B Spaces at
Housing — Liquid crystal polymer,
black, 94V-0 rated
Contacts — Copper alloy; duplex
plated .000030 [0.00076] gold in
mating area, .000150 [0.000381] tin on
solder tail, with entire contact under-
plated .000050 [0.00127] nickel
.025
[0.64]
= C
.140
[3.56]
.085
[2.16]
.340
[8.64]
.305
[7.75]
Holddown — Copper alloy; plated
.0000150 [0.00381] tin over .000050
[0.00127] nickel
.190
[4.83]
(2 Plc)
.175
[4.45]
.063
[1.57]
(2 Plc)
.100
[2.54]
Min
.136
[3.45]
(2 Plc)
Related Product Data
Mating Receptacles — pages 20
and 26
D
Recommended PC Board Layout
Note: Refer to TE Customer
Drawings for additional PC board
layout information and dimensional
tolerances.
Performance Specifications
page 29
—
Technical Documents — page 29
Product Specification 108-1443
Application Specification
114-7010
Header
Dimensions
No. of
Pos.
Part Numbers
Latching
Packaging
— Tube
A
B
C
D
Non-Latching
10
20
30
40
50
60
70
80
100
.630 [16.00]
.880 [22.35]
1.130 [28.70]
1.380 [35.05]
1.630 [41.40]
1.880 [47.75]
2.130 [54.10]
2.380 [60.45]
2.880 [73.15]
9
.225 [5.72]
.475 [12.07]
.725 [18.42]
.975 [24.77]
1.225 [31.12]
1.475 [37.47]
1.725 [43.82]
1.975 [50.17]
2.475 [62.87]
.550 [13.97]
.800 [20.32]
1.050 [26.67]
1.300 [33.02]
1.550 [39.37]
1.800 [45.72]
2.050 [52.07]
2.300 [58.42]
2.800 [71.12]
5-104895-1
5-104895-2
5-104895-3
5-104895-4
5-104895-5
5-104895-6
5-104895-7
5-104895-8
6-104895-0
5-104894-1
5-104894-2
5-104894-3
5-104894-4
5-104894-5
5-104894-6
5-104894-7
5-104894-8
6-104894-0
19
29
39
49
59
69
79
99
Note: All part numbers are RoHS compliant.
24
Catalog 82012
Revised 4-12
Dimensions are shown for
Dimensions are in inches
and millimeters unless
otherwise specified.
