METRIC
Ribbon Cable Interconnect Solutions
Dimensions are
millimeters over inches
2.0 mm [.079] Receptacle Connectors
Product Facts
I
True hard metric 2.0 x 2.0
[.079 x .079] mating grid for
1.0 [.039] pitch ribbon cable
Wide selection of
configurations, 8-50
positions
Insulation displacement
(IDC), beryllium copper
contacts, duplex plated
gold-over-nickel
Top/bottom single beam
contact orientation
UL 94V-0 rated thermo-
plastic components
Assemblies are furnished
preassembled with
termination covers
Optional polarization
Optional strain relief
available
Connector assemblies
packaged for ease of
handling and protection
Recognized under the
Component Program
of the Underwriters
Laboratories, Inc.
UL File No. E28476
Certified by the
Canadian Standards
Association,
File No. LR 7189
I
I
.039
[1.00]
Centerline Ribbon Cable Connectors
.079
[2.00]
Receptacle Connectors
I
I
I
I
I
I
I
R
I
R
Performance Data
Durability
— 150 cycles
Termination Resistance
—
25 milliohms max.
Mating Force
—
1.67 N max. per contact
Unmating Force
—
0.14 N min. per contact
Operating Temperature
—
-65°C to +105°C
Technical Documents
Product Specification
108-1372
Application Specification
114-40038
The 2.0 [.079] receptacle
connector family features
contacts on a true 2.0 x 2.0
[.079 x .079] mating grid
for 1.0 [.039] pitch 28 AWG
ribbon cable. A variety of
configurations are available
from 8 through 50 positions.
This small, compact
connector is finding wide
acceptance throughout the
electronic industry, particu-
larly in the smaller laptop
and notebook type comput-
ers with 63.5 [2.5] drives.
Other areas of application
include point-of-sale termi-
nals, fax machines, photo-
copiers, printers, consumer
electronics, and other com-
puter peripheral equipment.
These receptacles feature
insulation displacement
contacts (IDC) with a
top/bottom single-beam
contact orientation.
Contacts are beryllium
copper, duplex plated
0.00076 [.000030] gold
in the mating area and
0.00254 [.000100] min.
tin on termination end, all
over 0.00127 [.000050]
nickel underplating. Contact
mating area is 1.54 [.061]
from the face of the housing
and they accept 0.50mm
[.0197] round or square
posts.
Housings are made of
UL 94V-0 rated polyester
with optional center bar
polarization. Complete
assemblies are furnished
preassembled with termina-
tion covers. The complete
assembly presents a com-
pact design only 5.2 [.203]
wide over the termination
cover by 4 [.157] deep by
4 [.157] wide mating end.
Terminated height is 8.48
[.334]. Optional strain relief
available. Assemblies are
packaged for ease of
handling and protection.
16
Catalog 82012
Revised 4-12
www.te.com
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
Dimensions are in inches
and millimeters unless
otherwise specified.
