Ribbon Cable Interconnect Solutions
Ultra ATA Bus Connectors, .025 [0.64] Centerline Ribbon Cable
(Continued)
Ultra ATA
Compatible Headers
Universal Headers — Pin 20 Omitted
Post
Type
Vertical
Vertical
Housing
Material
Nylon or PBT
Nylon or PBT
Latch
Type
Long
Short
Part
Number
5111824-9
6489700-1
Contact Finish
(Plating Code)
D
B
Solder Tail
Length
.110
2.79
.123
3.12
Comments
PP
Legend:
PP — Polarization Peg
.025
[0.64]
Centerline Ribbon Cable Connectors
Ultra ATA Bus Connectors
Low Profile Headers — Pin 20 Omitted
Post
Type
Vertical
Vertical
Vertical
Vertical
Vertical
Vertical
Housing
Material
Nylon
Nylon
Nylon 6T
Nylon 6T
Nylon
Nylon
Latch
Type
None
None
None
None
None
None
Part
Number
1888188-1
1888188-2
2-1734161-4
2-1734161-5
1734162-2
1734162-4
Contact Finish
(Plating Code)
A
B
C
C
C
C
Solder Tail
Length
.120
3.05
.120
3.05
.122
3.10
.122
3.10
.110
2.79
.110
2.79
Housing
Color
Black
Black
Black
Blue
Black
Blue
Plating Code A
— Duplex plated, gold flash on mating surfaces, .000100 [0.00254] min. tin on solder area, with entire
post underplated .000050 [0.00127] min. nickel.
Plating Code B
— Duplex plated, gold flash over palladium-nickel, .000015 [0.00038] min. total on mating surfaces,
.000100 [0.00254] min. tin on solder area, with entire post underplated .000050 [0.00127] min. nickel
or
.000015
[0.00038] min. gold on mating surfaces, .000100 [0.00254] min. tin on solder area, with entire post underplated
.000050 [0.00127] min. nickel.
Plating Code C
— Gold flash over nickel underplate on entire post.
Plating Code D
— Duplex plated, gold flash over palladium-nickel, .000030 [0.00076] min. total on mating surfaces,
.000100 [0.00254] min. tin on solder area, with entire post underplated .000050 [0.00127] min. nickel
or
.000015
[0.00038] min. gold on mating surfaces, .000100 [0.00254] min. tin on solder area, with entire post underplated
.000050 [0.00127] min. nickel.
Note:
All part numbers are RoHS compliant.
15
Catalog 82012
Revised 4-12
www.te.com
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
Dimensions are in inches
and millimeters unless
otherwise specified.
