NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Application Tooling
For more information, request
SDE die sets provide cost-
effective flexibility, through
many options for a common
die-set outline. The SDE die
sets can be adapted for use
with CERTI-CRIMP hand
tools, PRO-CRIMPER III hand
tools, the SDE Terminator
and the 626 Pneumatic Tool
System.
SDE (Standard Die
Envelope) Die Sets
Mechanical Hand Tools
for Interchangeable Die
Sets
Catalog 1654003.
These tools are ideal for small pro-
duction, prototype and
experimental applications. They
are used for terminating pin and
socket contacts to wire and fea-
ture a ratchet device to provide
consistently formed crimps.
For use with Type III+ contacts,
see pages 17-19.
For more information, request
Catalog 1773379-1, Instruction
Sheet 408-9930.
Commercial grade hand
tool for crimping various
products. Features ratchet
control to provide complete
crimp cycle. Accepts both
pinned- and shouldered-
style die sets. Locators are
provided with pinned-style
die sets for proper contact
and wire positioning, and
to help minimize contact
rotation and bending during
crimping. Approximate
PRO-CRIMPER III Hand
Tool, Part No. 58495-1
weight 1.3 lb [0.60 kg].
For Type III+ contacts, see pages
17-19.
For more information, request
Catalog 65780.
Premium grade hand tools.
Feature ratchet control to
provide complete crimp
cycle. Die sets close in
CERTI-CRIMP Straight
Action Hand Tools (SAHT)
a straight line. Include a
contact locator and wire
stop, plus an insulation crimp
adjustment lever, when
applicable. Approximate
weight 1.3 lb [0.59 kg].
For subminiature coaxial
contacts, see pages 22-23.
For more information, request
Catalog 65780, Instruction Sheet
408-2095.
Premium grade hand tool.
Features ratchet control
to provide complete crimp
cycle. The interchangeable
die sets close in a straight
line to minimize contact
or terminal rotation during
crimping. When applicable,
user-assist features such as
a contact or terminal locator
and a wire stop, are built into
the die set. Approximate
weight 1.9 lb [0.86 kg].
CERTI-CRIMP “C” Head
Straight Action Hand Tool
(SAHT), Part No. 69710-1
For more information, request
Catalog 1654714.
An electric crimp terminator
with compact design features
a die set holder that is
Electric Machine for
Interchangeable Die Sets
SDE Terminator,
Part No. 1490076-2
compatible with all AMP SDE
(PRO-CRIMPER III Tool) die
sets. Hand- or foot-actuated
options are available. CE
Approved.
90
Catalog 82003
Revised 06-08
