NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Application Tooling (Continued)
Interchangeable applicators
for crimping products in
AMP-O-MATIC Stripper-
Crimper Machines. Consist
of separate ram and
lower tooling assemblies.
Similar dial-in settings for
different wire sizes and
insulation diameters as HDM
applicators. Available with
sensors for use with the
Crimp Quality Monitor.
The Cosmic 30M is a high
precision, high speed
Stripper-Crimper
Applicators (coded SCA)
Cosmic 30M Wire Strip-
ping Machine, 5-528367-0
electrical wire stripper that
is very easy to operate. It’s
equipped with a four blade
system and an optional
gripper for more difficult
wires. There is a digital
display for the wire diameter
that can be set at 0.01 mm
increments.
For more information, request
Catalog 1773385-2.
For more information, request
Catalog 65004 (AMP-O-MATIC
Stripper-Crimper Machines),
Catalog 82275 [Crimp Quality
Monitor (CQM)].
The compact, lightweight,
benchtop Cosmic 927R was
designed and developed
to reliably strip various
insulation materials and
micro-cable. From conductor
diameter 36 to 10 AWG, the
stripping diameter display
can be set to within 0.1 mm
increments.
Cosmic 927R Micro-Cable
Stripper
STRIPPER-CRIMPER MACHINES
Semiautomatic bench
crimping machines that
also strip the wire, and
AMP-O-MATIC Stripper-
Crimper Machines, Part
Nos. 1320895-1, -2
are therefore used for
terminating jacketed cable.
Feature manual precision
adjustment of crimp height,
keyed strip blades for faster,
more accurate setups, and
an efficient scrap removal
system. All adjustments can
be made from the front of
the machines without special
tools. Available with crimp
quality monitoring.
For more information, request
Catalog 1773385-4.
For more information, request
Catalog 65004, Video 198075,
Catalog 82275 [Crimp Quality
Monitor (CQM)], Video 198094.
The combination of the
Stripping Module with the
AMP 3K/40 and AMP 5K/40
Terminating Machines or
the AMP-O-LECTRIC Model
“G” Terminator provides an
economic and proficient
method of stripping the
wire and crimping terminals
on the same machine. The
module accepts End- and
Side-Feed HDM Applicators
(32-14 AWG) and operates
in three modes: crimp only,
strip only, or strip and crimp.
It can be installed on existing
machines in the field or
purchased as one unit from
the factory.
Stripping Module (for the
AMP 3K/40 and AMP
5K/40 Terminating
Machines and AMP-O-
LECTRIC Model “G”
Terminator on page 77)
For more information, request
Catalog 1309085.
