NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Application Tooling (Continued)
LEAD MAKERS
APPLICATORS
This fully-automatic, PC-
controlled leadmaker can be
equipped with up to three
processing stations enabling
the crimping of both ends
of the wire, double-crimp
connections with three
Interchangeable applicators
for crimping products reeled
end-to-end (primarily open-
barrel terminals). Used in
bench and lead-making
machines; most designs can
be used, or adapted for use
with minor tooling changes,
dial-in settings for different
wire sizes and insulation
diameters. Mechanical or
air-powered feed systems,
depending on the product
applied.
Komax gamma 333 PC
Lead-Making Machine
End-Feed Heavy-Duty
Miniature Applicators
(coded HDM)
different contacts, single-
ended seal applications,
tinning or ink-jet marking.
Features include ultra-short
conversions times, easy-to-
use graphic-based TopWin
interface with multiple-
language capability, crimp
force analyzer with statistical
analysis, seal monitoring, and
integrated good/bad sorting.
For more information, request
Catalog 296393-2 and Instruction
Sheet 408-8039.
For more information, request
Catalog 1307901.
The new EDGE counter
tracks wearable tool usage
for the most effective
EDGE Applicator Counter
The AMPOMATOR System III
Leadmaker is designed for
the demands of low-volume/
high mix manufacturing
and precision quality. This
leadmaker combines the best
wire processing capabilities
with new technologies in
terminal feeding and machine
set-up found in the System III
Applicator to offer signifi-
cant advantages for higher
throughput and efficiencies.
AMPOMATOR System III
Leadmaker
maintenance planning.
The completely electronic
counter, with clear LCD
display, indicates cycles since
installation. By performing
maintenance at measured
intervals with pre-set limits,
operators avoid breakdowns
and rejects caused by tool
wear or mis-adjustment. A
wireless interface transfers
counters to a PC running
the optional Edge Counter
Software Pack.
For more information, request
Catalog 1654956-5
The EDGE is standard on all
new applicators and can be
retrofitted to most existing
Tyco Electronics applicators.
The 433-S alpha offers
maximum flexibility for
Komax 433-S alpha
Lead-Making Machine
For more information, request
Catalog 1773385..
applying seals to one or
both ends of the wire with
the corresponding terminal.
When equipped with the mci
711 crimp terminator and mci
761 seal applicator, the fully-
automated 433-S alpha forms
a highly compact system
with optimum accessibility.
Dynamic servo-drives provide
fine travel settings on all
motor axes and the wire
straightening unit with quick-
release lock and automatic
lead-in feature reduces wire
changeover time. The TopWin
software provides for fast,
simple data input.
Interchangeable applicators
for crimping products reeled
side-by-side on single or
dual carrier strips (primarily
closed-barrel terminals
and open-barrel contacts).
Similar design as the end-
feed version. All side-feed
applicators include a wire
stop to help correctly
Side-Feed Heavy-Duty
Miniature Applicators
(coded HDM)
position the wire end in the
crimping target area.
For more information, request
Catalog 296393-2 and Instruction
Sheet 408-8040.
For more information, request
Catalog 1307801.
93
Catalog 82003
Revised 06-08
