NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Protective Hardware (Continued)
Shields, One-Piece,
180° and 90° Cable
Exit
A
A
C
(Assembled)
C
Material and Finish
Shields and Cable Clamps -
Steel, nickel plated
(Short,
D
Assembled)
D
(Short)
(Short)
D
(Long)
Screws - Steel, zinc plated
C
(Long,
Assembled)
One-Piece Shields are used to
protect connectors from dust,
dirt and physical damage and
to provide strain relief for the
contacts. They feature integral
cable clamps formed at 180°
and 90° and are available in
long and short versions. Long
versions offer pin protection
as well as connector protec-
tion and strain relief. Short
versions may be used in com-
bination with Pin Hoods to
provide pin protection.
B
B
90° Cable Exit
180° Cable Exit
Note: Typical 180° and 90° Cable Exit Shields are illustrated. Slight differences in configuration exist for
various sizes.
For shielding and fastening
applications, One-Piece
Shields are used with Locking
Springs. They cannot be used
with Jackscrews.
One-Piece Shields may be
secured to a connector hous-
ing using other appropriate
hardware such
One-Piece Shields, 180° Cable Exit (Long and Short)
Connectors Used On (No. of Positions)
Max.
Dimensions
Shield Part No.
Special Application
Cable
Dia.
Standard
High
Mixed
A
B
C
D
Long
Short
Voltage
2.468 1.969
as Guide Pins and Sockets.
201378-2
—
62.69 50.01
.531 1.312
.375
9.53
14
—
—
Tyco Electronics does NOT
recommend the use of shields
with posted connectors
because of the potential of
shorting.
13.49 33.32
1.796 1.300
45.62 33.02
—
201360-2
201227-2
201169-2
—
.515 1.640 1.796 1.300
13.08 41.66 45.62 33.02
.350
—
20
26
—
—
8.89
.640 1.687 1.796 1.296
16.26 42.85 45.62 32.92
.400
15
—
201384-2
—
—
10.16
2.468 1.969
62.69 50.01
.828 2.062
21.03 52.37
.500
12.7
34
16
20
1.781 1.281
45.24 32.54
201165-2
One-Piece Shields, 90° Cable Exit (Short)
Connectors Used On (No. of Positions)
Special Application
Max.
Cable
Dia.
Dimensions
Shield Part No.
Short
A
B
C
D
Standard
High
Mixed
Voltage
.828 2.062 2.562 1.812
21.03 52.37 65.07 46.02
.500
12.7
201469-2
34
16
20
Note: All parts are packaged unassembled.
86
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
Dimensions are shown for USA: 1-800-522-6752
reference purposes only. Canada: 1-905-470-4425
Specifications subject Mexico: 01-800-733-8926
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
www.tycoelectronics.com equivalent U.S. Customary Units. to change.
C. America: 52-55-5-729-0425 UK: 44-141-810-8967
