ML145157
LANSDALE Semiconductor, Inc.
ML145157 BLOCK DIAGRAM
14–BIT SHIFT REGISTER
14
f
R
ENB
REFERENCE COUNTER LATCH
14
LOCK
DETECT
LD
PD
OSC
14–BIT
÷
R COUNTER
in
out
out
PHASE
DETECTOR
A
OSC
REF
out
PHASE
DETECTOR
B
φ
φ
V
14–BIT
÷
N COUNTER
14
f
in
R
÷
N COUNTER LATCH
14
f
V
1–BIT
CONTROL
S/R
DATA
CLK
S/R
out
14–BIT SHIFT REGISTER
PIN DESCRIPTIONS
the control bit is at a logic low. A logic low on this pin allows
the user to change the data in the shift registers without affect-
ing the counters. ENB is normally low and is pulsed high to
transfer data to the latches.
INPUT PINS
fin
Frequency Input (Pin 8)
OSCin, OSCout
Reference Oscillator Input/Output (Pins 1, 2)
Input frequency from VCO output. A rising edge signal on
this input decrements the ÷ N counter. This input has an invert-
er biased in the linear region to allow use with AC coupled sig-
nals as low as 500 mV p–p. For larger amplitude signals (stan-
dard CMOS logic levels), DC coupling may be used.
These pins form an on–chip reference oscillator when con-
nected to terminals of an external parallel resonant crystal.
Frequency setting capacitors of appropriate value must be con-
nected from OSC to ground and OSC
to ground. OSC
in out
in
may also serve as the input for an externally–generated refer-
CLK, DATA
Shift Clock, Serial Data Inputs (Pins 9, 10)
ence signal. This signal is typically AC coupled to OSC , but
in
for larger amplitude signals (standard CMOS logic levels) DC
coupling may also be used. In the external reference mode, no
Each low–to–high transition of the clock shifts one bit of
data into the on–chip shift registers. The last data bit entered
determines which counter storage latch is activated; a logic
1selects the reference counter latch and a logic 0 selects the
÷ N counter latch. The entry format is as follows:
connection is required to OSC
.
out
OUTPUT PINS
PD
out
Single–Ended Phase Detector A Output (Pin 5)
This single–ended (three–state) phase detector output pro-
duces a loop–error signal that is used with a loop filter to con-
trol a VCO.
Frequency fV > fR or fV Leading: Negative Pulses
Frequency fV < fR or fV Lagging: Positive Pulses
Frequency fV = fR and Phase Coincidence:
High–Impedance State
FIRST DATA BIT INTO SHIFT REGISTER
ENB
Latch Enable Input (Pin 11)
φR, φV
Double–Ended Phase Detector B Outputs (Pins 16, 15)
These outputs can be combined externally for a loop–error
signal. A single–ended output is also available for this purpose
A logic high on this pin latches the data from the shift regis-
ter into the reference divider or ÷ N latches depending on the
control bit. The reference divider latches are activated if the
control bit is at a logic high and the ÷ N latches are activated if
(see PD ).
out
Page 18 of 35
www.lansdale.com
Issue A
