ML145156
LANSDALE Semiconductor, Inc.
ML145156 BLOCK DIAGRAM
RA2
RA1
RA0
12 x 8 ROM REFERENCE DECODER
12
LOCK
DETECT
12–BIT
÷ R COUNTER
OSC
in
LD
OSC
REF
out
f
PHASE
DETECTOR
A
CONTROL LOGIC
R
out
PD
out
f
V
MC
PHASE
DETECTOR
B
7–BIT
÷
A COUNTER
10–BIT
÷
N COUNTER
10
f
φ
in
V
φ
R
7
V
SW2
SW1
DD
ENB
LATCH
÷
A COUNTER LATCH
7
÷
N COUNTER LATCH
10
DATA
CLK
2–BIT SHIFT
REGISTER
7–BIT SHIFT REGISTER
10–BIT SHIFT REGISTER
A COUNTER BITS
N COUNTER BITS
PIN DESCRIPTIONS
INPUT PINS
f
in
Frequency Input (Pin 10)
Input to the positive edge triggered ÷ N and ÷ A counters.
is typically derived from a dual–modulus prescaler and is
LAST DATA BIT IN (BIT NO. 19)
FIRST DATA BIT IN (BIT NO. 1)
f
in
AC coupled into the device. For larger amplitude signals (stan-
dard CMOS logic levels), DC coupling may be used.
ENB
Latch Enable Input (Pin 13)
When high (1), ENB transfers the contents of the shift reg-
ister into the latches, and to the programmable counter inputs,
and the switch outputs SW1 and SW2. When low (0), ENB
inhibits the above action and thus allows changes to be made
in the shift register data without affecting the counter program-
ming and switch outputs. An on–chip pull–up establishes a
continuously high level for ENB when no external signal is
applied. ENB is normally low and is pulsed high to transfer
data to the latches.
RA0, RA1, RA2
Reference Address Inputs (Pins 20, 1, 2)
These three inputs establish a code defining one of eight
possible divide values for the total reference divider, as defined
by the table below:
Total
Divide
Value
Reference Address Code
RA2
RA1
RA0
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
8
64
OSC , OSC
in
out
Reference Oscillator Input/Output (Pins 19, 18)
128
256
640
1000
1024
2048
These pins form an on–chip reference oscillator when con-
nected to terminals of an external parallel resonant crystal.
Frequency setting capacitors of appropriate value must be con-
nected from OSC to ground and OSC
to ground. OSC
in out
in
may also serve as the input for an externally–generated refer-
ence signal. This signal is typically AC coupled to OSC , but
in
for larger amplitude signals (standard CMOS logic levels) DC
coupling may also be used. In the external reference mode, no
CLK, DATA
Shift Register Clock, Serial Data Inputs (Pins 11, 12)
Each low–to–high transition clocks one bit into the on–chip
19–bit shift register. The data input provides programming in-
formation for the 10–bit ÷ N counter, the 7–bit ÷ A counter,
and the two switch signals SW1 and SW2. The entry format is
as follows:
connection is required to OSC
.
out
TEST
Factory Test Input (Pin 16)
Used in manufacturing. Must be left open or tied to V
.
SS
