How to order
Cannon Order reference
CA
3106
E
18–
1
S
X
B
–
***
Series
Shell style
Class
Shell size
Contact arrangement
Contact type
Insulator position
Connectors with bayonet coupling
Dash
Modification
Explanation
Series
Connector style D or
CA3106E-B and CA3106F-B CA3106F-B-13/-14/-15
CA – Circular connectors with bayonet coupling
Connector style G, M, R1 or CA3106E-B-02/-03/-06
Shell style
CA3106E-B-13/-14/-15 and CA3106E-B-32 with shrink boot,
straight, acc. VG95343
3100 – Wall mounting receptacle
3101 – Cable connecting receptacle
3102 – Box mounting receptacle
3105 – Dummy receptacle for front and panel mounting
3106 – Plug, straight
3108 – Plug, 90°
TBF – Bulkhead receptacle
Class
E – environmental with resilient insulators and endbell with
clamp and bushing
F – environmental with resilient insulator and endbell for flex tube
R – environmental with resilient insulator and shortened
light-weight endbell without cable clamp
Shell size
10SL, 12S, 14S, 16S, 16, 18, 20, 22, 24, 28, 32 and 36
Contact arrangement
See pages 13 to 26
Contact type
P – Pin
S – Socket
PS – one side pin, one side socket (only for TBF)
Insulator position
Besides the normal position further insulator positions are
possible for Cannon connectors (see page 13-23) to prevent
mismating. Polarization is achieved by turning the pin contact
insulator clockwise towards the shell, the socket insulator,
however, in opposite clockwise direction. This information refers
to the mating side of the contact insulator. For special insert
alternations of standard inserts see page 24.
Modification
see page 12
Dimensions shown in mm
Specifications and dimensions subject to change
www.ittcannon.com
11
