D Subminiature
Commercial Micro D — MDSM
PCB Connector 90° - Single
Note: Standard jackpost offering recommended for use with .060 panel.
Part Numbers - Single
No. of
Contacts
A
max.
C
max.
D
max.
F
Thumbscrew
Push/Pull
B
E
0,05 (.002)
9
15
25
MDSM-9PE-Z10-VR25*
MDSM-15PE-Z10-VR22
MDSM-25PE-Z10-VR17
MDSM-9E-Z42-VR25*
MDSM-15PE-Z42-VR22
MDSM-25PE-Z42-VR17
19,90 (.783)
23,60 (.929)
29,95 (1.179)
14,35 (.565)
18,16 (.715)
24,51 (.965)
8,60 (.339)
12,30 (.484)
18,65 (.734)
9,00 (.354)
12,90 (.508)
19,25 (.758)
5,08 (.200)
8,89 (.350)
15,24 (.600)
10,24 (.403)
14,01 (.551)
20,35 (.801)
*For use with SSA applications
PCB Connector 90° - Stacked
Part Numbers - Stacked
No. of
Contacts
A
max.
C
max.
D
max.
Thumbscrew
Push/Pull
B
E
F
18
30
MDSM-18PE-Z10-VR25*
MDSM-30PE-Z10-VR22
MDSM-18PE-Z42-VR25*
MDSM-30PE-Z42-VR22
19,90 (.783)
23,50 (.925)
14,35 (.565)
18,16 (.715)
8,60 (.339)
9,00 (.354)
5,08 (.200)
8,89 (.350)
10,24 (.403)
14,00 (.551)
12,30 (.484)
12,71 (.500)
*For use with SSA applications
Dimensions are shown in mm (inch)
Dimensions subject to change
99
