D Subminiature
Commercial Micro D — MDSM
Contact Crimping Tools
Parallel Action Low Volume Hand Tool
Hand Tool
Semi-Automatic Crimper/Stripper
Part Number: CCTP-MDS
Part Number: CCTR-MDS
Part Number: ABT-620-MDS (Lease Only)
Note: For use with individual contacts (break off reel
MDS-S-TS or MDS-S-RL.
Note: For use with reeled contacts - Part Number MDS-S-TS.
Note: For use with reeled contacts - Part Number MDS-S-RL.
For additional information, see page 275.
Crimp dies for SSA Cable will be offered by ITT Cannon.
Consult factory for details.
Contact Insertion/Extraction Tools
Jackpost Tool
Insertion Tool
Part Number: CIET-MDSM
Part Number: 120090-0102
Note: For use with Z10 Jackpost.
Note: Contacts cannot be removed from MDSM connectors.
Shield Crimp Tooling
ɀ Shield crimping requires four items; one
press, one locator, and one each of the two
dies listed below.
Hand Press
Pneumatic Press
ɀ Locator and Dies for Shield Termination
Ordered Separately
Part Numbers
Layout
9
Locator
Die
317-8666-013
317-8666-014
317-8666-016
274-8649-332/274-8649-333
274-8649-334/274-8649-335
274-8649-338/274-8649-339
15
25
Note: For assembly instructions and crimping information, refer
to Manual # MY-1/190.
Part Number: CHP-MDSM-SR
Part Number: CPT-MDSM-SR
Dimensions are shown in mm (inch)
Dimensions subject to change
