D Subminiature
Commercial Micro D — MDSM
Pinout
SSA External Cable Wiring Table
P1
P2
CONTACT #5
CONTACT #1
CONTACT #9
CONTACT #6
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
8,51
(.335)
MAX
Note: Shield connected to both shells.
External Cable Pinouts
P1
P2
Pin
2
Signal Name
Pin
4
Signal Name
LineIn−
LineOut−
LineOut+
LineIn−
LineIn+
6
9
LineIn+
4
2
LineOut−
LineOut+
9
6
Note: Pins 1, 3, 5, 7 and 8 are not connected.
SSA External Cable Wire Cross Section (For Reference Only)
CONDUCTOR
INSULATION
FILLER
Ø 5,72
(.225)
INNER SHIELD
Ø 1,57
(.062)
OUTER SHIELD
JACKET
Transfer Impedance Performance
Requirements for External SSA Connections
Frequency MHz
Value (dB-Ohm)(max.)
30
159
500
−25
−16
−10
Dimensions are shown in mm (inch)
Dimensions subject to change
103
